COMNAV VOYAGER X3 CLASS A AIS SYSTEM

PRODUCT OVERVIEW

The ComNav Voyager X3 features a high-contrast 3.5-inch monochrome LCD and is fully compliant with IMO and IEC standards for Class A AIS. Unlike Class B units, the Voyager X3 transmits at higher power (12.5W) and uses SOTDMA technology to ensure its position is reported with priority, even in high-traffic shipping lanes. It is designed to enhance situational awareness by displaying the position, speed, heading, and cargo information of all AIS-equipped vessels within VHF range.

The system is highly integrated, containing the VHF transmitter, two TDMA receivers, a 70-channel DSC receiver, and a high-sensitivity GPS receiver within a single compact housing. It is engineered to feed real-time target data to the ship's Radar and ECDIS via NMEA 0183 or NMEA 2000. Its intuitive interface and dedicated "target" list allow the officer of the watch to quickly identify potential collision risks and communicate directly with other vessels via VHF.

TECHNICAL SPECIFICATIONS

-- Model: Voyager X3

-- Manufacturer: ComNav Marine Ltd. (Canada)

-- Display: 3.5-inch Monochrome Backlit LCD

-- AIS Class: Class A (SOLAS Compliant)

-- Frequency Range: 156.025 to 162.025 MHz

-- Power Output: 12.5 Watts (High) / 2 Watts (Low)

-- Receivers: 2x TDMA, 1x DSC (Channel 70)

-- Interfaces: 3x NMEA 0183 Outputs, 1x NMEA 2000, RS-232, Pilot Plug

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 10 Watts (Average)

-- Waterproofing: IPX6 (Front Panel)

-- Compliance: IMO MSC.74(69), IEC 61993-2, Wheelmark Certified

KEY FEATURES & APPLICATIONS

-- SOLAS Class A Compliance: Meets all international requirements for mandatory AIS carriage on commercial vessels over 300 GT, ensuring full regulatory approval.

-- Advanced Target Management: Displays a comprehensive list of nearby vessels, including Name, MMSI, CPA (Closest Point of Approach), and TCPA (Time to CPA).

-- Integrated Pilot Plug: Features a front-panel or external Pilot Plug, allowing maritime pilots to quickly connect their laptops or PPU (Portable Pilot Units) for precise harbor navigation.

-- NMEA 2000 Ready: Includes high-speed NMEA 2000 connectivity, making it easy to integrate with the latest generation of MFDs (Multi-Function Displays) and digital bridge systems.

-- Silent Mode Option: Allows the vessel to stop transmitting its position while still receiving data from other ships—a critical feature for security in specific maritime zones.

-- Robust Vibration Resistance: Built to exceed IEC 60945 standards, ensuring the electronics remain stable even on high-vibration engine-room decks or tugboats.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished ComNav Voyager X3 units from the Alang yards go through a comprehensive "RF Stress Test." We focus on the VHF Transceiver, ensuring it maintains a full 12.5W output and clear modulation. The LCD backlight is checked for consistency, and the Pilot Plug pins are inspected for wear. We also perform a software update and verify the MMSI reset capability so the unit is ready for your vessel's specific data. Every unit is factory-reset at our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

ComNav Voyager X3, Furuno FA-150, Furuno FA-170, JRC JHS-182, JRC JHS-183, Samyung SI-30, McMurdo Smartfind M2, Saab R4, Simrad AI80, Em-trak A100.
