PRE OWNED FURUNO IC-115 FURUNO IC-115 MARINE ANTENA

I apologize for the frustration. I see what is happening: when I use bullet points (the little dots *), some website editors "strip" that formatting and pull all the text together into one big paragraph.

To fix this once and for all for your "copy and paste" needs, I will stop using bullet points. Instead, I will use simple dashes and extra line breaks. This is the most "web-safe" way to ensure your description stays organized.

Here is the FELCOM 15 IC-115 again in the safest plain-text format:

FURUNO IC-115 ANTENNA UNIT (FOR FELCOM 15)

PRODUCT OVERVIEW

The Furuno IC-115 is a robust, high-performance antenna unit designed for the Inmarsat-C satellite network. As the outdoor component of the FELCOM 15 system, it provides high-quality, two-way data and telex links between vessels at sea and shore-based stations.

The IC-115 is an omni-directional "Daisy" type antenna, meaning it does not require a complex tracking mechanism to maintain a satellite lock, making it exceptionally reliable in heavy seas. Encased in a weather-resistant radome, it is built to withstand extreme maritime conditions, including high winds, salt spray, and ice.

TECHNICAL SPECIFICATIONS

-- Model: Furuno IC-115

-- System Compatibility: Furuno FELCOM 15 (Inmarsat-C)

-- Antenna Type: Omni-directional (Helical)

-- Frequency Range: TX: 1626.5 - 1646.5 MHz | RX: 1530.0 - 1545.0 MHz

-- Polarization: Right-Hand Circular (RHCP)

-- Output Power: 17 W (at final amplifier)

-- G/T (Gain-to-Noise Temperature): -23 dB/K (at 5 degree elevation)

-- Power Supply: 12-24 VDC (Powered via Terminal Unit IC-215)

-- Operating Temperature: -35C to +70C

-- Waterproofing: IP56 (Exposed unit)

-- Weight: 1.4 kg (Approx.)

KEY FEATURES & APPLICATIONS

-- Maintenance-Free Design: With no moving parts inside the radome, the IC-115 eliminates the mechanical failures common in larger tracking antennas.

-- GMDSS Compliance: When paired with the FELCOM 15 terminal, it meets full SOLAS/GMDSS requirements for safety and distress alerting.

-- Global Messaging: Supports all Inmarsat-C services including E-mail, Telex, EGC (SafetyNET/FleetNET), and Data Reporting/Polling.

-- Compact & Lightweight: Its small footprint allows for flexible installation on mast-tops or radar arches without adding significant wind load.

-- Easy Interfacing: Connects to the IC-215 processor unit via a single coaxial cable.

-- High-Impact Radome: The UV-stabilized housing protects the internal helical element from the corrosive marine environment.

TYPICAL CONDITION (USED/REFURBISHED)

In the Bhavnagar refurbishing yards, the IC-115 is a high-demand item. Used units are carefully inspected for any cracks in the radome or corrosion at the connector base. Refurbished units are tested for "Loop-back" signal strength to ensure the internal LNA and SSPA are performing within factory gain specifications.

COMPATIBLE BRAND MODELS:

Furuno (FELCOM 15, FELCOM 12, IC-215, IC-116, IC-118, FELCOM 18, FELCOM 19), JRC (JUE-85, JUE-87, NAF-742, NAF-253GM), Thrane & Thrane / Sailor (TT-3005M, TT-3026, TT-3606E), Cobham (Sailor 6110), Nera (WorldClass C), Skanti (Scansat-700), Samyung (SN-100).
