PRE OWNED JRC NWZ-4570 JRC NWZ-4570 MARINE GPS

The JRC NWZ-4570 is a 5.7-inch monochrome STN LCD unit designed specifically for the professional bridge environment. It serves as the "brain" and visual interface for JRC's IMO-compliant GPS systems. Known for its high-contrast "Silver Bright" screen, the NWZ-4570 provides exceptional readability under varying light conditions, from the harsh glare of tropical sunlight to the complete darkness of a midnight watch.

The unit is more than just a monitor; it contains the processing power to handle complex navigational calculations, route management, and NMEA data distribution. Its rugged construction and tactile membrane keypad are designed to withstand the heavy-duty use characteristic of commercial shipping, making it a reliable standard for thousands of vessels worldwide.

TECHNICAL SPECIFICATIONS

-- Model: NWZ-4570

-- Manufacturer: JRC (Japan Radio Co., Ltd.)

-- Display Type: 5.7-inch Monochrome STN LCD

-- Resolution: 320 x 240 Pixels (VGA)

-- Backlight: Adjustable (Multi-level for night vision protection)

-- Controls: Tactile keypad with dedicated Function, NAV, and MOB keys

-- Internal Memory: Storage for waypoints, routes, and track history

-- Interfaces: Connection ports for GPS Antenna, NMEA 0183 (In/Out), and Power

-- Supply Voltage: 12V to 24V DC

-- Operating Temperature: -15°C to +55°C

-- Waterproofing: IPX5 (Front panel)

-- Compatibility: Primary display for JLR-7700, JLR-7800, and JNAV-500 series

KEY FEATURES & APPLICATIONS

-- Interchangeable Design: Functions as a universal display for several JRC GPS models, making it an essential spare part for marine electronic traders and technicians in the Alang yard.

-- Optimized Navigation Displays: Offers multiple viewing modes including Plotter (track visualization), Highway (3D steering), and Digital Data (large-format coordinates and speed).

-- Professional Data Management: Allows for the rapid entry of up to 2,000 waypoints and 100 routes, with a dedicated Man Overboard (MOB) button for emergency marking.

-- NMEA 0183 Synchronization: Distributes precise position and timing data to Radars, AIS, and VDR systems via integrated output buffers.

-- Durable Marine Build: The housing is resistant to salt-air corrosion and high-frequency vibrations commonly found in large vessel wheelhouses.

-- User-Centric Keypad: Features large, clearly labeled buttons that provide physical feedback, ensuring accurate operation even when the vessel is pitching in heavy seas.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished NWZ-4570 units from Alang ship-recycling undergo a strict multi-point technical restoration. We focus heavily on LCD contrast and pixel health, ensuring there are no "dead spots" or fading. The keypad membrane is checked for integrity and responsiveness. We also perform a comprehensive test of the internal processor and NMEA ports to ensure stable data communication with external sensors. Every unit is factory-reset and provided with a detailed test report from our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

JRC NWZ-4570, JRC JLR-7700, JRC JLR-7700 MK2, JRC JNAV-500, Furuno GP-150, Furuno GP-90, Koden KGP-920, Tokyo Keiki G-1.
