PRE OWNED FURUNO FA-170 FURUNO FA-170 MARINE AIS

PRODUCT DATA SHEET: FURUNO FA-170 CLASS-A AIS (USED/REFURBISHED)

PRODUCT OVERVIEW

The Furuno FA-170 is a premium, IMO-compliant Class-A AIS transponder that brings modern visualization to the bridge with its 4.3-inch color LCD. Designed for commercial ships, workboats, and SOLAS-regulated vessels, the FA-170 is more than just a transponder; it is a critical collision-avoidance tool. As a used or refurbished unit, the FA-170 offers a significant upgrade over older monochrome models, providing a LAN interface for easy network integration and full compliance with Bridge Alert Management (BAM) standards.

TECHNICAL SPECIFICATIONS

Model: Furuno FA-170

Display Unit: 4.3" Color LCD (WQVGA 480 x 272 pixels)

Transponder Unit: FA-1701 (Compact Black Box)

Frequency Range: 156.025 MHz to 162.025 MHz

Output Power: 12.5 W or 1 W (Automatic/Manual)

Target Capacity: Tracks up to 2,048 AIS targets and AIS-SARTs

GNSS Receiver: 12-channel parallel receiver (GPS/GLONASS/SBAS)

Interfaces: * 6x Serial I/O ports (IEC 61162-1/2)

1x LAN (Ethernet 100Base-TX) for bridge networking

1x Alarm Output (Contact Closure)

1x Pilot Plug (Optional external unit)

Power Supply: 12-24 VDC (3.0–6.0 A)

Environmental: IP22 (Monitor), IP20/22 (Transponder), IP56 (Antenna)

KEY FEATURES & APPLICATIONS

High-Resolution Color Display: The 4.3" screen uses color-coded symbols to differentiate between vessel types, base stations, and dangerous targets, allowing for instant recognition.

Bridge Alert Management (BAM): Fully compliant with IMO MSC.302(87), ensuring seamless connection to centralized bridge alarm systems.

Advanced Networking: Unlike older models, the FA-170 features a LAN (Ethernet) port, allowing for simplified data sharing with Furuno NavNet, FAR-series Radars, and ECDIS.

AIS-SART & MOB Tracking: Provides dedicated symbols and prioritized alerts for Life-saving Search and Rescue Transponders and Man Overboard devices.

Dangerous Target List: Automatically sorts and highlights vessels that pose a collision risk based on user-defined CPA (Closest Point of Approach) and TCPA limits.

Inland AIS Ready: Includes specialized operational modes for European Inland Waterway requirements (Blue Sign support).

Compact "Space-Saving" Design: The monitor unit is designed for easy flush-mounting in crowded consoles, and a retrofit kit is available to fit it into the same cutout as an older FA-150.

TYPICAL CONDITION (USED/REFURBISHED)

Display Health: Color LCDs are checked for "dead pixels" or color degradation.

Component List: Usually sold as a set including the FA-1701 Transponder, FA-1702 Monitor, and GPA-017S GPS Antenna.

Software: Refurbished units are typically updated to the latest firmware to ensure compatibility with modern Bridge Alert Management systems.
