PRE OWNED FURUNO FAR - 1623 FURUNO FAR - 1623 MARINE RADAR

PRODUCT DATA SHEET: FURUNO 1623 COMPACT MARINE RADAR

PRODUCT OVERVIEW

The Furuno 1623 is a 2.2 kW X-Band radar that combines a slim-line 6-inch monochrome LCD with a lightweight 15-inch radome antenna. Perfectly suited for vessels as small as 17 feet, it offers professional-grade features—such as Guard Zone Alarms and Watchman Mode—in a user-friendly package. Known for its exceptional short-range target discrimination, the 1623 is a reliable choice for navigating narrow channels, harbors, and coastal waters in low-visibility conditions.

TECHNICAL SPECIFICATIONS

Model: Furuno 1623 (MODEL1623)

Display: 6" Silver Bright Monochrome LCD (240 x 320 pixels)

Output Power: 2.2 kW Peak

Antenna: 15-inch Radome (RSB-0093)

Max Range: 16 Nautical Miles (NM)

Range Scales: 13 scales from 0.125 to 16 NM

Rotation Speed: Tri-speed (24/31/41 RPM) – automatically adjusts based on range scale

Beam Width: Horizontal 6.2°, Vertical 25°

Power Supply: 12-24 VDC (Low consumption: 36W typical / 8W Watchman mode)

Waterproofing: IPX5 (Display), IPX6 (Antenna)

KEY FEATURES & APPLICATIONS

High-Contrast "Silver Bright" LCD: Provides 4 levels of gray tones for excellent target separation and is easily readable in direct sunlight or total darkness.

Tri-Speed Antenna: Automatically increases rotation speed at shorter ranges (up to 41 RPM) to provide faster target updates during high-stakes maneuvers in tight harbors.

Watchman Mode: A power-saving feature where the radar "wakes up" at timed intervals (5, 10, or 20 mins) to check the Guard Zone for targets before returning to standby.

Advanced Target Detection: Utilizing narrower pulselengths and dual IF bandwidths, it provides superior clarity for close-range objects like buoys and small craft.

Navigation Data Overlay: When connected to an external GPS, the screen can display position, speed (SOG), course (COG), and a "lollipop" waypoint mark for easier navigation.

User-Friendly Controls: Features an ergonomic "Omni Pad" for rapid cursor movement and a dedicated [PROG] key for menu shortcuts.

Reverse Video Mode: Allows the operator to switch to white targets on a black background to reduce eye fatigue during night watches.

TYPICAL CONDITION (USED/REFURBISHED)

Display Integrity: Used units are typically inspected for the "silvering" of the LCD and backlight consistency.

Radome Condition: The 15-inch dome is often checked for internal gear wear and magnetron life hours.

Replacement Value: Frequently used as a direct replacement for vessels already fitted with older Furuno 1600-series mounts and cabling.
