PRE OWNED FURUNO FAR-2117 FURUNO FAR-2117 MARINE RADAR

PRODUCT DATA SHEET: FURUNO FAR-2117 ARPA RADAR (USED/REFURBISHED)

PRODUCT OVERVIEW

The Furuno FAR-2117 is a high-performance, 12 kW X-Band ARPA radar designed for commercial vessels under 10,000 GT. Part of the legendary FAR-21x7 series, it is celebrated for its exceptional target detection and rugged reliability. As a used or refurbished unit, the FAR-2117 offers a cost-effective way for shipowners to maintain SOLAS compliance while benefiting from Furuno's sophisticated signal processing and "Silver Bright" display technology.

TECHNICAL SPECIFICATIONS

Model: Furuno FAR-2117 (X-Band)

Output Power: 12 kW

Antenna Type: Open Array (available in 4 ft, 6.5 ft, or 8 ft radiators)

Rotation Speed: 24 rpm (Standard) or 42 rpm (HSC - High Speed Craft)

Frequency: 9410 MHz ± 30 MHz (X-Band)

Range Scales: 0.125 to 96 Nautical Miles (NM)

ARPA Capacity: Automatic or manual acquisition/tracking of up to 100 targets

AIS Capacity: Displays up to 1,000 AIS targets (when interfaced with AIS transponder)

Display Interface: DVI-D (Digital Video Interface) for crisp SXGA (1280 x 1024) resolution

Power Supply: 24 VDC or 115/230 VAC (Processor), 230/440 VAC (Antenna)

KEY FEATURES & APPLICATIONS

Advanced Signal Processing: Features multi-level quantization, echo stretch, and echo averaging for superior target detection in heavy rain and sea clutter.

Target Tracking (TT/ARPA): Provides critical data for collision avoidance, including CPA (Closest Point of Approach) and TCPA (Time to CPA) for tracked targets.

Networkability: Up to four sets of FAR-21x7/28x7 radars can be interconnected via Ethernet (100 Base-TX) without the need for an external interswitch.

Customizable Operation: The RCU-014 Control Unit features a full keyboard and a high-precision trackball, with customizable function keys for one-touch access to specific radar modes.

Dual Guard Zones: Two independent guard zones can be set to alert the navigator of any incoming targets within a specific sector or distance.

Radar Map Overlay: Supports the creation of radar maps with up to 20,000 points, allowing operators to mark fairways, buoys, and navigational hazards directly on the screen.

Versatile Display Modes: Supports Head-up, Course-up, North-up, and True Motion (TM) orientations for different navigational requirements.

TYPICAL CONDITION (USED/REFURBISHED)

Standard Components: Usually includes the RPU-013 Processor, RCU-014 Keyboard, and the RSB-096 Gearbox with an X-Band radiator.

Refurbishment Notes: Used units are typically checked for magnetron life hours and gearbox seal integrity to ensure long-term performance in offshore environments.
