PRE OWNED FURUNO FAR-2228 BB FURUNO FAR-2228 BB MARINE RADAR

PRODUCT DATA SHEET: FURUNO FAR-2228 BB X-BAND RADAR

PRODUCT OVERVIEW

The Furuno FAR-2228 BB is a 25 kW Black Box X-Band radar designed for professional mariners who require superior target detection and high reliability. As a "Black Box" system, it consists of a powerful processor unit that can be connected to Furuno’s 19", 23", or 27" monitors, or other third-party IMO-compliant displays. It features Furuno’s latest signal processing technology, including Automatic Clutter Elimination (ACE) and Fast Target Tracking, ensuring unparalleled situational awareness in even the most challenging weather conditions.

TECHNICAL SPECIFICATIONS

Model: Furuno FAR-2228 BB (Black Box)

Frequency / Band: X-Band (9410 MHz)

Output Power: 25 kW

Antenna Type: Open Array (Available in 4 ft, 6.5 ft, or 8 ft radiators)

Range Scales: 0.125 to 96 Nautical Miles (NM)

Target Tracking (TT): Automatic or manual tracking of up to 100 targets

AIS Capacity: Displays up to 350 targets (interfaced with AIS transponder)

Processor Unit: RPU-025 (High-speed signal processing)

Connectivity: Ethernet (100Base-TX) for Bridge Integration and Interswitching

Power Supply: 100-230 VAC (Processor) / 24 VDC (Optional)

Rotation Speed: 24 rpm (Standard) or 42 rpm (HSC - High Speed Craft)

KEY FEATURES & APPLICATIONS

Automatic Clutter Elimination (ACE): A one-touch function that intelligently adjusts gain and sea/rain clutter filters. ACE recognizes and eliminates "ghost" echoes and noise while reinforcing genuine targets.

Fast Target Tracking™: Provides accurate speed and course vectors for acquired targets in mere seconds, allowing for immediate and informed collision-avoidance decisions.

Ethernet-Based Architecture: The antenna unit directly converts analog signals to digital before sending them via Ethernet to the processor below deck, resulting in higher signal accuracy and easier maintenance.

Ergonomic Control Unit: Features the RCU-014 (Full Keyboard) or RCU-031 (Trackball) controllers, designed for stress-free operation during long night watches.

Widescreen Compatible: Supports modern widescreen monitor formats (e.g., MU-270W), allowing for more data boxes and information to be displayed without obstructing the radar sweep (PPI).

Simplified Maintenance: The gearbox has been redesigned with a brushless DC motor and a modular internal block that can be easily removed for servicing, reducing long-term cost of ownership.

Retrofit Friendly: Compatible with existing cables and mounts from the previous FAR-2xx7 series, making it an ideal choice for upgrading aging bridge systems.

TYPICAL CONDITION (USED/REFURBISHED)

Components: Usually includes the RPU-025 Processor, RCU-014 Control Unit, and RSB-128 Gearbox.

Inspection: Used units are typically verified for magnetron life and the integrity of the Ethernet data link between the antenna and processor.
