PRE OWNED FURUNO FAR-3000 FURUNO FAR-3000 MARINE RADAR

PRODUCT OVERVIEW

The Furuno FAR-3000 is a MED-certified Chart Radar series that redefines bridge operations by merging advanced target detection with electronic charting. Available in both X-Band and S-Band (including Magnetron-free Solid State options), the FAR-3000 offers an intuitive user interface designed to reduce officer workload. With its "InstantAccess bar™" and high-speed signal processing, it provides unparalleled situational awareness for large commercial vessels, tankers, and passenger ships.

TECHNICAL SPECIFICATIONS

Model Range: FAR-3210 / FAR-3220 (X-Band), FAR-3230S (S-Band), FAR-3220-NXT (Solid State)

Display Options: 19", 23.1", or 27" Wide Color LCD (High Resolution)

Output Power: * X-Band: 12 kW or 25 kW

S-Band: 30 kW (Magnetron) or 250 W (Solid State NXT)

Detection Features: ACE (Automatic Clutter Elimination) & Fast Target Tracking™

Network: Ethernet 1000Base-T (for Interswitch and Sensor Integration)

Interface: 8x Serial I/O ports (IEC 61162-1/2), 2x DVI-D, 1x LAN, 4x USB 2.0

Tracking: TT (Target Tracking) and AIS target overlay (up to 2,000 targets)

Power Supply: 100-230 VAC (Processor), 100-230 VAC (Monitor)

KEY FEATURES & APPLICATIONS

Automatic Clutter Elimination (ACE): A revolutionary one-touch function that automatically adjusts gain and clutter filters (Sea/Rain) based on weather conditions for a crystal-clear echo image.

Chart Overlay & ECDIS Integration: Allows the operator to overlay radar echoes directly onto official ENC charts, making it easier to distinguish between navigational hazards and moving targets.

Solid State Technology (NXT): The S-Band and X-Band NXT models are magnetron-free, requiring significantly less maintenance while providing improved detection of small targets and better performance in heavy weather.

Intuitive User Interface: Utilizes a Status Bar and InstantAccess bar™ similar to modern software, allowing for task-based operations without digging through complex menu trees.

Fast Target Tracking™: Provides accurate heading and speed vectors for acquired targets in just seconds, allowing for immediate collision-avoidance decisions.

Redundancy & Flexibility: Designed as part of a Multi-Function Display (MFD) workstation, allowing the user to switch between Radar, ECDIS, and Conning displays at any station on the bridge.

Fan-less Antenna Design: (S-Band Only) Reduces mechanical wear and long-term maintenance costs.

TYPICAL CONDITION (USED/REFURBISHED)

Processor Health: Used units are typically supplied with the EC-3000 Processor and are checked for the latest software firmware compatibility.

Control Units: Often paired with the RCU-025 Keyboard or RCU-026 Trackball units.

Display Quality: 27" Wide screens are highly sought after in the used market for their ability to display multiple data boxes without obstructing the radar sweep.
