PRE OWNED FURUNO FBB-250 FURUNO FBB-250 DOM MARINE ANTENA

PRODUCT OVERVIEW

The FBB-250 dome is a 3-axis stabilized tracking antenna designed to provide uninterrupted broadband connectivity over the Inmarsat I-4 satellite network. It is the standard solution for vessels that require faster data than the 150-series (up to 284 kbps) but do not have the space or budget for the larger 500-series domes.

Equipped with high-precision rate sensors and brushless motors, the FBB-250 antenna maintains a constant satellite lock despite the vessel’s rolling, pitching, or high-speed maneuvers. It supports simultaneous high-quality voice calls and standard IP data, making it the primary choice for modern fleet management, electronic chart updates (ENC), and crew welfare.

TECHNICAL SPECIFICATIONS

-- Common Models: Sailor TT-3050A / Furuno FB-1250 / JRC JUE-251

-- Antenna Type: 3-axis stabilized tracking antenna

-- Standard IP Data: Up to 284 kbps (Receive/Transmit)

-- Streaming IP: 32, 64, 128 kbps (Guaranteed rates)

-- Voice Services: 4 kbps AMBE+2 / 3.1 kHz Audio (Fax/Analog)

-- Transmit Frequency: 1626.5 MHz to 1660.5 MHz

-- Receive Frequency: 1525.0 MHz to 1559.0 MHz

-- Power Supply: 10.5V to 32V DC (Powered via Below Deck Unit)

-- Operating Temperature: -25C to +55C (Exposed Equipment)

-- Waterproofing: IP56 (Weatherproof Radome)

-- Antenna Dimensions: 276 mm (Height) x 329 mm (Diameter)

-- Antenna Weight: 4.2 kg to 5 kg (Depending on brand)

-- Interface: Single TNC or N-Type 50 Ohm connector

KEY FEATURES & APPLICATIONS

-- Balanced Performance: Delivers significantly higher data speeds than Mini-C or FBB-150 units while remaining small enough for easy installation on masts of all sizes.

-- Advanced Tracking: The internal mechanical stabilization system uses GPS and motion sensors to ensure zero signal loss in sea states with extreme motion.

-- Global Office Capability: Supports VPN, encrypted email, and multi-user web browsing, allowing the ship to function as a remote office anywhere in the world.

-- Simultaneous Service: Enables the use of a telephone handset while data is being transmitted, ensuring the bridge is never cut off from voice communication.

-- Low Maintenance: Built with a high-impact radome that protects the internal RF electronics from UV radiation, salt-water ingress, and heavy vibration.

-- Easy Retrofit: Often shares similar mounting patterns with older Inmarsat systems, making it a popular choice for refurbished upgrades in the Bhavnagar market.

TYPICAL CONDITION (USED/REFURBISHED)

Sourcing an FBB-250 dome from Alang/Bhavnagar ship-recycling yards is a common practice for vessel operators looking for cost-effective spares. Refurbished units undergo a strict "tracking test" to ensure the motors are silent and responsive. We verify that the LNA (Low Noise Amplifier) provides the correct gain for Inmarsat-C/FBB reception and check the radome for any structural fatigue or seal degradation.

COMPATIBLE BRAND MODELS:

Sailor / Thrane & Thrane (TT-3050A, TT-3052A, Sailor 250, Sailor 150), Furuno (FELCOM 250, FB-1250, FELCOM 500, FB-1500), JRC (JUE-251, JUE-250, JUE-501), Cobham (Sailor 6110, 6120), Intellian (FB250, FB500), KVH (TracPhone V3, V7), Samyung (SBB-250).
