PRE OWNED FURUNO FE-700 FURUNO FE-700 MARINE ECHO SOUNDER

The Furuno FE-700 is a professional-grade depth sounder that meets the stringent IMO standards for all ships. It features a high-brightness 6.5-inch color TFT LCD that displays depth in clear, easy-to-read numerals alongside a graphical echogram. Unlike older models that used mechanical paper belts, the FE-700 utilizes internal memory to store up to 24 hours of depth data, which can be played back at any time.

The system is designed for maximum versatility, allowing for the connection of either 50 kHz or 200 kHz transducers. The 200 kHz frequency is ideal for high-resolution sounding in shallow waters and ports, while the 50 kHz frequency provides powerful penetration for deep-sea tracking. With its compact display unit and integrated transceiver, it is easily installed in bridge consoles where space is at a premium.

TECHNICAL SPECIFICATIONS

-- Model: FE-700

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 6.5-inch Color TFT LCD

-- Frequency: 50 kHz or 200 kHz (Single frequency)

-- Output Power: 600 W (RMS)

-- Depth Ranges: 5, 10, 20, 40, 100, 200, 400, 800 meters

-- Accuracy: +/- 2.5% of range

-- Data Memory: 24 hours (Recording at 1-minute intervals)

-- Interfaces: 2x NMEA 0183 Outputs (DPT, DBT), 1x NMEA Input

-- Supply Voltage: 100-230V AC or 24V DC

-- Alarms: Shallow water, Depth, Power failure

-- Compliance: IMO Res. A.224(VII), MSC.74(69) Annex 4

KEY FEATURES & APPLICATIONS

-- Paperless Recording: Eliminates the need for costly consumables by storing 24 hours of depth data internally. This data can be reviewed on-screen to comply with port state inspections.

-- Draft Offset: Allows the navigator to adjust the displayed depth to reflect either depth-below-keel or depth-below-surface, which is critical for safe maneuvering in shallow channels.

-- High-Contrast Display: The color TFT LCD offers multiple color palettes (including night mode) to ensure the echogram is visible under all bridge lighting conditions.

-- Dual-System Integration: Provides clean NMEA 0183 output to interface directly with VDRs (Voyage Data Recorders), ECDIS, and integrated bridge systems.

-- Reliable Digital Tracking: Uses advanced signal processing to filter out noise and aeration, ensuring a stable bottom lock even in turbulent sea conditions.

-- Logbook Function: Automatically logs the date, time, and coordinates (when connected to GPS) alongside depth readings for comprehensive record-keeping.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished FE-700 units from the Alang yards undergo a rigorous testing process. We verify the transceiver performance to ensure the 600W output is consistent and the sensitivity is high. The 6.5-inch LCD is inspected for clarity and backlight life. We also test the internal memory backup battery and ensure the NMEA data strings are broadcasting correctly for VDR integration. Every unit is reset to factory defaults and supplied with a test report from our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Furuno FE-700, Furuno FE-800, Furuno FE-701, JRC JFE-380, JRC JFE-582, JRC JFE-680, Consilium E1, Consilium E2, Skipper GDS-101, Sperry Marine ES-5100, Raytheon Anschütz GDS-102.
