PRE OWNED FURUNO FMD-3100 FURUNO FMD-3100 MARINE ECDIS

The Furuno FMD-3100 is an IMO-compliant Electronic Chart Display and Information System that features a 24-inch widescreen LCD. Unlike larger modular systems, the FMD-3100 utilizes an integrated design where the processor is built directly into the monitor unit. This significantly reduces the cabling requirements and footprint on the bridge, making it an ideal choice for retrofitting older vessels with restricted console space.

Despite its compact size, the FMD-3100 shares the same powerful user interface as the larger FMD-3200 and FMD-3300 models. It offers lightning-fast chart redrawing and an intuitive "Task-Based" operation system. Mariners can easily switch between planning, monitoring, and data management tasks using the dedicated trackball control unit or the on-screen menu system, ensuring high operational efficiency during critical maneuvers.

TECHNICAL SPECIFICATIONS

-- Model: FMD-3100

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 24-inch Widescreen Color TFT LCD

-- Resolution: 1920 x 1080 Pixels (Full HD)

-- Integrated Processor: High-speed RISC Architecture

-- Chart Formats: S-57 Ed. 3 (ENC), S-63 (Encrypted), C-MAP ADMIRALTY, ARCS

-- Interfaces: 4x NMEA 0183 (Inputs/Outputs), 1x LAN (Ethernet), 2x USB 2.0

-- Power Supply: 100-230V AC or 24V DC

-- Data Storage: Solid State Drive (SSD) for enhanced durability

-- Compliance: IMO MSC.232(82), IEC 61174 Ed. 4, IEC 62288, IEC 61162

-- Installation: Table-top or Flush Mount

KEY FEATURES & APPLICATIONS

-- All-in-One Design: Combines the processor and the 24-inch display into a single sleek unit, saving valuable bridge space while maintaining full IMO compliance.

-- Task-Based User Interface: Features a "Status Bar" and "Instant Access Bar" that provide immediate entry to essential functions, reducing menu-diving during navigation.

-- Advanced Route Planning: Includes comprehensive tools for route creation, safety checking, and ETD/ETA calculations, with automatic detection of navigational hazards along the path.

-- Radar and AIS Overlay: Seamlessly overlays ARPA targets and AIS data onto the electronic chart to provide the bridge team with superior situational awareness.

-- Fast Chart Redraw: Utilizing Furuno’s advanced chart engine, the system provides nearly instantaneous zooming and panning, even with multiple data layers active.

-- Paperless Navigation: When installed in a dual configuration (Master/Backup), the FMD-3100 meets all SOLAS requirements for paperless navigation, eliminating the need for physical charts.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished FMD-3100 units from the Alang yards are meticulously tested for hardware and software integrity. We verify the Full HD LCD for brightness consistency and ensure there are no dead pixels. The internal SSD is checked for read/write speed and data health. We also perform a factory reset and ensure the latest Furuno firmware is installed, confirming that the NMEA data ports and Ethernet connection are fully operational for seamless bridge integration.

COMPATIBLE BRAND MODELS:Furuno FMD-3100, Furuno FMD-3200, Furuno FMD-3300, Furuno FAR-2117, Furuno FAR-2127, Furuno FAR-3000 Chart Radar, JRC JAN-9201, Danelec DM-800, Sperry Marine VisionMaster FT.
