PRE OWNED FURUNO FMD-3200 FURUNO FMD-3200 MARINE ECDIS

The Furuno FMD-3200 is an IMO-compliant ECDIS featuring a 19-inch high-resolution display and a powerful, separate processor unit (EC-3000). Unlike the all-in-one FMD-3100, the 3200’s modular design allows for a customized bridge layout, making it the preferred choice for deep-sea commercial vessels. The system is built around a new, sophisticated chart-drawing engine that eliminates redraw latency, providing instantaneous zooming and panning—even when displaying complex ENC data, AIS targets, and radar overlays simultaneously.

The FMD-3200 introduces a task-based user interface with a "Status Bar" and "InstantAccess Bar," which streamlines navigational workflows. This design allows officers to perform critical tasks—such as route monitoring or safety contour adjustments—with minimal clicks, significantly enhancing situational awareness during heavy traffic or poor visibility.

TECHNICAL SPECIFICATIONS

-- Model: FMD-3200 (Standard 19" LCD) / FMD-3200-BB (Black Box)

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Monitor Unit: 19-inch Color LCD (MU-190)

-- Resolution: 1280 x 1024 Pixels (SXGA)

-- Processor Unit: EC-3000

-- Control Units: RCU-024 (Keyboard/Trackball) or RCU-026 (Trackball Only)

-- Chart Support: IHO/S-57 Ed. 3 (ENC), S-63, C-MAP ADMIRALTY, ARCS Raster Charts

-- Connectivity: 8x Serial I/O ports, 1x Digital IN, 6x Digital OUT, 2x LAN ports

-- Radar Overlay: Integrated via Ethernet with FAR-2xx7, FAR-2xx8, and FAR-3000 series

-- Power Supply: 100-230V AC (Main) with 24V DC Auto-Backup

-- Compliance: IMO MSC.232(82), IEC 61174 Ed. 4, IEC 62288, IEC 62923-1/2 (BAM)

KEY FEATURES & APPLICATIONS

-- Instantaneous Chart Redraw: Furuno’s advanced engine ensures that the chart follows the navigator’s actions in real-time, removing the "frozen screen" risk common in older systems.

-- Task-Based Interface: The InstantAccess Bar provides quick entry to functions like "Check Route," "Safety Contour," and "Chart Legend," changing dynamically based on the current operational mode.

-- Seamless Sensor Integration: Acts as a central hub using the Sensor Adapter (MC-3000 series) to gather data from Gyros, AIS, Logs, and Sounders, distributing it across the bridge network.

-- AIO (Admiralty Information Overlay): Displays temporary and preliminary notices to mariners directly on the ENC, ensuring the vessel always complies with the latest safety warnings.

-- Paperless Navigation: When installed in a dual-station configuration, the FMD-3200 fully satisfies SOLAS requirements for paperless sailing, reducing the administrative burden of chart management.

-- Radar & Conning Capability: Beyond ECDIS, the system can function as a Conning Information Display or a Chart Radar, providing a unified multi-function display (MFD) experience.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished FMD-3200 systems from Alang are subjected to a rigorous certification process. We focus on the EC-3000 Processor Unit, testing the internal cooling systems and ensuring the Solid State Drive (SSD) is healthy for fast data retrieval. The MU-190 monitor is checked for consistent brightness and port integrity (DVI/VGA). We also verify that the RCU-024 control unit has a responsive trackball and that all functional keys are operational. Every unit is reset to factory standards with the latest stable firmware for S-63 1.2 compliance.

COMPATIBLE BRAND MODELS:Furuno FMD-3200, Furuno FMD-3100, Furuno FMD-3300, Furuno FAR-2117, Furuno FAR-2827, Furuno FAR-3000, Furuno GP-170, JRC JAN-9201, Sperry Marine VisionMaster FT, Tokyo Keiki EC-8100/8600.
