PRE OWNED FURUNO GP-170 D FURUNO GP-170 D MSRINE GPS

The Furuno GP-170D features a 5.7-inch high-resolution color LCD that provides exceptional data clarity. As the "D" model, it includes an internal DGPS beacon receiver, allowing it to process correction signals from terrestrial stations to achieve position accuracy within 5 meters. It is fully compliant with the latest IMO performance standards and is a critical component for safe navigation in narrow channels, busy ports, and during precision berthing maneuvers.

Designed for the modern integrated bridge, the GP-170D serves as a master position sensor. It is equipped with advanced noise rejection technology and multi-path mitigation, ensuring a stable bottom lock and position fix even in areas with significant signal interference. Its networking capabilities allow it to act as a central hub, distributing high-accuracy position, SOG, and COG data to the entire bridge suite, including Radar, ECDIS, and AIS.

TECHNICAL SPECIFICATIONS

-- Model: GP-170D

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 5.7-inch Color TFT LCD

-- Resolution: 640 x 480 Pixels (VGA)

-- Receiver Type: 12-channel parallel GPS / SBAS / DGPS (Beacon)

-- Position Accuracy: DGPS: 5m, SBAS: 7m, GPS: 10m

-- Beacon Frequency: 283.5 to 325.0 kHz

-- Storage: 1,000 Waypoints, 2,000 Track Points, 100 Routes

-- Interfaces: 5x NMEA 0183 Outputs, 1x NMEA 0183 Input, LAN (Ethernet), USB

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 1.2 A (at 12V)

-- Compliance: IMO MSC.112(73), IEC 61108-4 (DGPS), Wheelmark Certified

KEY FEATURES & APPLICATIONS

-- Internal DGPS Beacon Receiver: Automatically locks onto the strongest local correction signal, providing sub-5-meter accuracy essential for specialized offshore and coastal operations.

-- High-Resolution Color Display: The VGA screen offers multiple color palettes and high-contrast modes, ensuring readability in the brightest sunlight or the darkest night-watch conditions.

-- BAM (Bridge Alert Management): Fully supports the latest BAM requirements, providing clear and categorized alerts for loss of signal, position deviation, or system faults.

-- LAN/Ethernet Connectivity: Includes a network port for high-speed data sharing with ECDIS and other PC-based navigation systems, simplifying bridge integration.

-- USB Data Port: Allows for easy backup of waypoints and routes, as well as software updates, directly via a standard USB flash drive.

-- Dual Antenna Support: Can be configured with two antennas for maximum redundancy, ensuring the vessel never loses its primary position source during critical transits.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished GP-170D units from Alang are put through an intensive technical restoration. We focus on the VGA LCD screen, ensuring the color calibration and backlight are perfect. The Beacon Receiver board is tested for sensitivity across the full frequency range. We also verify the LAN and NMEA 0183 output buffers to ensure all five ports are delivering stable, synchronized data strings. Every unit is supplied with a high-performance GPA-021S antenna and is factory-reset at our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Furuno GP-170D, Furuno GP-150, Furuno GP-170, Furuno GP-90, JRC JNAV-500, JRC JAN-9201, Koden KGP-920, Sperry Marine NAVIGAT, Tokyo Keiki G-1, Samyung GP-290.
