PRE OWNED FURUNO GP-32 FURUNO GP-32 MARINE GPS

The Furuno GP-32 is a high-performance GPS navigator designed for a wide range of vessels, from fishing boats to commercial ships. In the Bhavnagar and Alang markets, it is considered one of the most reliable and "bulletproof" GPS units ever made, prized for its high-sensitivity receiver and clear, easy-to-read display.

FURUNO GP-32 COMPACT GPS NAVIGATOR

PRODUCT OVERVIEW

The Furuno GP-32 is an advanced GPS navigator with a WAAS (Wide Area Augmentation System) receiver, providing highly accurate position data. It features a high-contrast 4.5-inch silver bright LCD that remains clearly visible even in direct sunlight. Unlike many modern touchscreen units, the GP-32 uses tactile buttons and a dedicated cursor pad, making it easy to operate with gloves or in rough sea conditions.

The system is designed to store up to 1,000 points of ship’s tracks and waypoints, with a memory capacity for 200 planned routes (up to 30 waypoints each). Its versatile display modes include Plotter, Highway, Steering, and Customizable Data screens. The GP-32 is also famous for its robust NMEA 0183 connectivity, allowing it to feed precise position, speed, and heading data to Radars, Fish Finders, Autopilots, and AIS systems.

TECHNICAL SPECIFICATIONS

-- Model: GP-32

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 4.5-inch Monochrome Silver Bright LCD

-- Resolution: 120 x 64 Pixels

-- Receiver Type: 12-channel parallel, WAAS ready

-- Position Accuracy: GPS: 10m (95%), WAAS: 3m (95%)

-- Storage: 1,000 Waypoints, 1,000 Track Points, 200 Routes

-- Interfaces: NMEA 0183 (Ver 1.5/2.0), RS-232C, Furuno Remote Display

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 240 mA (at 12V)

-- Waterproofing: IPX5 (Display Unit)

-- Alarms: Arrival, Anchor Watch, XTE (Cross Track Error), Speed, WAAS, Time

KEY FEATURES & APPLICATIONS

-- High-Sensitivity WAAS Receiver: Significantly improves position accuracy by using ground-based correction signals, providing precision within 3 meters.

-- Versatile Display Modes: Includes a "Highway" mode that provides a 3D perspective for easy route following and a "Steering" mode for precise course keeping.

-- NMEA 0183 Data Distribution: Acts as a primary position sensor for the entire bridge, sending GPRMC, GPGGA, and GPVTG strings to connected electronics.

-- Rugged Marine Design: Built to withstand the salt air and high vibrations common in the Indian maritime industry.

-- User-Friendly Interface: Features "Hot Keys" and a simple menu structure that allows for rapid waypoint entry and route creation.

-- Compact Footprint: Its small size allows for easy flush-mounting in crowded consoles or bracket-mounting on the bridge dashboard.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished GP-32 units from the Alang yards go through a comprehensive restoration process. We focus on the LCD screen clarity, ensuring there is no "sunburn" or fading on the display. The Internal Battery (for memory backup) is tested and replaced if necessary to ensure waypoints are not lost. We also verify the Antenna Connector and the GPA-017 antenna for high signal-to-noise ratios. Every unit is bench-tested for NMEA data output stability and factory-reset before leaving our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Furuno GP-32, Furuno GP-31, Furuno GP-33, Furuno GP-39, Furuno GP-150, JRC JNAV-500, Koden KGP-913, Garmin GPS 128, Garmin GPS 152, Samyung GP-280.
