PRE OWNED FURUNO GP-37 FURUNO GP-37 MARINE GPS

The Furuno GP-37 is a compact, waterproof DGPS navigator featuring a high-contrast 4.5-inch silver bright LCD. While it shares a similar body to the GP-32, the GP-37 is equipped with a sophisticated dual-channel beacon receiver. This allows the unit to receive correction signals from terrestrial DGPS beacon stations, bringing position accuracy down to less than 5 meters.

The system is designed to store up to 1,000 waypoints and 200 routes, making it an excellent tool for repetitive coastal transits or marking specific underwater locations. Its "Highway" display mode provides a 3D perspective of the intended track, which is particularly useful for steering the vessel in narrow channels or during low-visibility conditions. With its robust NMEA 0183 output, the GP-37 serves as a precision data source for Radars, Autopilots, and Fish Finders.

TECHNICAL SPECIFICATIONS

-- Model: GP-37

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 4.5-inch Monochrome Silver Bright LCD

-- Resolution: 120 x 64 Pixels

-- Receiver Type: 12-channel parallel GPS + 2-channel Beacon receiver

-- Position Accuracy: DGPS: 5m (95%), GPS: 10m (95%)

-- Beacon Frequency: 283.5 to 325.0 kHz

-- Storage: 1,000 Waypoints, 1,000 Track Points, 200 Routes

-- Interfaces: NMEA 0183 (Ver 1.5/2.0), RS-232C

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 340 mA (at 12V)

-- Waterproofing: IPX5 (Display Unit)

-- Alarms: Arrival, Anchor Watch, XTE, Speed, DGPS, Time

KEY FEATURES & APPLICATIONS

-- Internal DGPS Beacon Receiver: Automatically searches for and locks onto the strongest local beacon station, providing enhanced accuracy without the need for additional external sensors.

-- High-Resolution Highway Mode: Offers a graphical "road" on the screen that makes cross-track error (XTE) easy to visualize and correct for precise course keeping.

-- Tactile Control Panel: Features dedicated "MARK" and "GOTO" buttons, ensuring that critical navigational actions can be performed instantly, even in rough weather.

-- Customizable Data Screens: Allows the operator to select which navigational parameters (Speed, COG, ETA, Position) are displayed in large, readable characters.

-- WAAS Capability: In areas without beacon coverage, the unit can utilize WAAS (Wide Area Augmentation System) satellites to maintain sub-10-meter accuracy.

-- Rugged Waterproof Housing: The display unit is built to withstand the salt-spray and high-temperature environments typical of the Indian coastline.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished GP-37 units from the Alang yards go through a meticulous inspection process. We specifically test the Beacon Receiver sensitivity to ensure it can still pull in weak terrestrial signals. The LCD contrast is checked for full visibility, and the internal backup battery is replaced to prevent the loss of user-saved waypoints. We also verify the NMEA Output to ensure it is correctly feeding position data to connected bridge equipment. Every unit is factory-reset and provided with a detailed test report from our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Furuno GP-37, Furuno GP-32, Furuno GP-36, Furuno GP-150D, JRC JNAV-500, Koden KGP-913D, Garmin GPS 128, Samyung GP-280, Matsutec HP-33.
