PRE OWNED FURUNO GP-39 FURUNO GP-39 MARINE GPS

The Furuno GP-39 features a 4.2-inch high-resolution color LCD that provides superior data visibility under all lighting conditions, including direct sunlight. It is equipped with a 12-channel GPS receiver integrated with SBAS (WAAS/EGNOS/MSAS) technology, delivering position accuracy within 3 meters. The GP-39 is designed to serve as a primary position source for the bridge, storing up to 3,000 track points, 10,000 waypoints, and 100 routes.

One of its most significant upgrades is the ability to share data across the bridge network. It can export GPS data to Fish Finders, Radars, and ECDIS via NMEA 0183. Furthermore, waypoints and routes can be easily exported or imported via a USB flash drive or a signal converter, making it highly convenient for fleet managers and navigators to synchronize data across multiple vessels.

TECHNICAL SPECIFICATIONS

-- Model: GP-39

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 4.2-inch Color TFT LCD

-- Resolution: 480 x 272 Pixels (WQVGA)

-- Receiver Type: 12-channel parallel, SBAS (WAAS/EGNOS/MSAS) ready

-- Position Accuracy: GPS: 10m, SBAS: 3m

-- Storage: 10,000 Waypoints, 3,000 Track Points, 100 Routes (30 waypoints each)

-- Interfaces: NMEA 0183, USB (for data backup/transfer)

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 0.7 A (at 12V)

-- Waterproofing: IP55 (Display Unit), IP56 (Antenna Unit)

-- Alarms: Arrival, Anchor Watch, XTE, Speed, WAAS, Time, Trip

KEY FEATURES & APPLICATIONS

-- High-Resolution Color Display: The WQVGA screen offers multiple display modes, including Plotter, Highway, Steering, Nav Data, and Satellite Monitor, all with vibrant color coding for easy interpretation.

-- Enhanced SBAS Accuracy: Utilizes satellite-based augmentation systems to provide high-precision positioning, essential for navigating narrow channels or performing precise offshore work.

-- USB Data Management: Allows for the effortless backup of waypoints and routes to a USB memory stick, ensuring that critical navigational data is never lost during system maintenance.

-- Seamless Retrofitting: The GP-39 is designed to be a "drop-in" replacement for the GP-32, using similar mounting dimensions and power requirements, making it an easy upgrade for existing Furuno users.

-- Multi-Language Support: Features a localized user interface supporting multiple languages, including English, French, Spanish, Chinese, and Vietnamese.

-- Tactile Button Interface: Uses a specialized 7-button control panel with a cursor pad, ensuring the unit can be operated accurately even in heavy seas or while wearing work gloves.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished GP-39 units from Alang ship-recycling yards are put through a strict quality-control protocol. We verify the Color LCD for brightness and ensure the protective bonding is intact. The USB port is tested for data transfer stability, and the NMEA 0183 output is checked with a signal analyzer to ensure accurate communication with external Radars and Autopilots. Every unit is supplied with the GPA-C01 antenna and is factory-reset at our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Furuno GP-39, Furuno GP-32, Furuno GP-33, Furuno GP-170, JRC JNAV-500, Koden KGP-915, Garmin GPSMAP 400 series, Samyung GP-290, ONWA KP-32, ONWA KP-128.
