PRE OWNED FURUNO GP-90 FURUNO GP-90 MARINE GPS

The Furuno GP-90 features a high-contrast 6-inch silver bright LCD that provides exceptional visibility in all bridge lighting conditions. It is engineered to meet the stringent IMO and IEC performance standards for global maritime trade. Unlike smaller leisure-grade units, the GP-90 is designed for high-speed tracking, ensuring that position, Speed Over Ground (SOG), and Course Over Ground (COG) are updated rapidly and accurately, even on vessels traveling at high velocities.

The system serves as a central hub for navigational data, equipped with multiple NMEA 0183 output ports to feed critical position information to Radars, AIS, ECDIS, and GMDSS equipment. It also features a dedicated Man Overboard (MOB) button and an intuitive menu system that allows for rapid route planning and waypoint management, storing up to 2,000 points of ship's tracks and waypoints.

TECHNICAL SPECIFICATIONS

-- Model: GP-90

-- Manufacturer: Furuno Electric Co., Ltd. (Japan)

-- Display: 6-inch Monochrome Silver Bright LCD (STN)

-- Resolution: 320 x 240 Pixels

-- Receiver Type: 12-channel parallel, WAAS/SBAS ready

-- Position Accuracy: GPS: 10m, WAAS: 3m, DGPS: 5m (with optional internal/external receiver)

-- Storage: 2,000 Waypoints, 2,000 Track Points, 100 Routes (up to 30 waypoints each)

-- Interfaces: 5x NMEA 0183 Outputs, 1x NMEA 0183 Input, 1x RS-232C

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 0.8 A (at 12V)

-- Waterproofing: IPX5 (Display Unit)

-- Compliance: IMO MSC.112(73), IEC 61108-1

KEY FEATURES & APPLICATIONS

-- High-Speed Craft (HSC) Mode: Optimized for vessels with high maneuvering speeds, providing stable and accurate position updates where standard GPS units might lag.

-- Extensive NMEA Connectivity: Features five independent output ports, allowing the unit to drive an entire suite of bridge electronics simultaneously without signal degradation.

-- Dual Display Capability: Can be configured to share data with a second GP-90 display unit, providing redundancy and allowing for position monitoring at multiple stations on the bridge.

-- Customizable Navigation Screens: The operator can choose between Plotter, Highway, Steering, and Nav Data modes, ensuring the most relevant information is always front and center.

-- DGPS Capability: Ready for differential GPS input, which can further enhance position accuracy for specialized operations like surveying or precision berthing.

-- Non-Volatile Memory: Ensures that all routes, waypoints, and user settings are preserved even during long periods of power-off during vessel maintenance or layup.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished GP-90 units from the Alang recycling yards undergo a rigorous multi-point technical restoration. We focus on the LCD contrast and backlight, ensuring the screen remains sharp for both day and night watches. The internal memory battery is replaced to protect your critical waypoints and routes. We also perform a stress test on all five NMEA output ports to guarantee they are broadcasting clean, stable data strings to your AIS and Radar systems. Every unit is factory-reset at our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Furuno GP-90, Furuno GP-150, Furuno GP-170, Furuno GP-80, JRC JNAV-500, Koden KGP-920, Sperry Marine NAVIGAT, Tokyo Keiki G-1, Samyung GP-290, Matsutec HP-33.
