PRE OWNED FURUNO IC-112 FURUNO IC-112 MARINE ANTENA

PRODUCT OVERVIEW

The Furuno IC-112 is an omni-directional antenna specifically designed for the FELCOM 12 Inmarsat-C Mobile Earth Station. This unit is built to provide stable satellite communication for telex, data reporting, and GMDSS distress alerting.

Because it is a passive/omni-directional helical antenna, it does not require a motor-driven tracking system, making it highly resistant to the constant vibration and motion of a vessel at sea. Its rugged, compact radome ensures the internal components remain protected from the corrosive effects of salt spray and extreme UV exposure.

TECHNICAL SPECIFICATIONS

-- Model: Furuno IC-112

-- System Compatibility: Furuno FELCOM 12 (Inmarsat-C)

-- Antenna Type: Helical (Omni-directional)

-- Frequency Range (TX): 1626.5 MHz to 1646.5 MHz

-- Frequency Range (RX): 1530.0 MHz to 1545.0 MHz

-- G/T Ratio: -23 dB/K minimum

-- EIRP: 12 to 14 dBW

-- Operating Temperature: -35C to +70C

-- Connector Type: N-Type Female (50 Ohm)

-- Radome Diameter: 156 mm (Approx.)

-- Mounting: 1-inch pipe thread (Standard marine mount)

KEY FEATURES & APPLICATIONS

-- GMDSS Reliability: Fully supports Inmarsat-C safety services, including SafetyNET and FleetNET, ensuring compliance for vessels operating in sea areas A1, A2, and A3.

-- No Moving Parts: The helical design eliminates the need for complex internal tracking motors, drastically reducing the chances of mechanical failure.

-- Legacy Support: A critical spare part for vessels still utilizing the FELCOM 12 terminal (IC-212), allowing for cost-effective repairs without replacing the entire bridge system.

-- Compact Footprint: Small and lightweight, making it easy to install on the highest point of the mast for an unobstructed 360-degree view of the sky.

-- Proven Durability: Widely known for surviving decades of service in the harshest global shipping lanes.

TYPICAL CONDITION (USED/REFURBISHED)

When sourcing an IC-112 from ship-breaking yards, we perform a thorough inspection of the radome seal and the antenna base. Refurbished units are tested for signal transmission (TX) and reception (RX) strength to ensure they meet the minimum Inmarsat-C link requirements. We also ensure the coaxial connector is cleaned and free of salt-corrosion (verdigris).

COMPATIBLE BRAND MODELS:

Furuno (FELCOM 12, FELCOM 15, IC-212, IC-115, IC-116, IC-118), JRC (JUE-75, JUE-85, NAF-741), Thrane & Thrane / Sailor (TT-3020C, TT-3022C, TT-3005M), Cobham (Sailor 6110), Nera (Saturn C), Skanti (Scansat-700), Samyung (SN-100).
