PRE OWNED FURUNO IC-116 FURUNO IC-116 MARINE ANTENA

PRODUCT OVERVIEW

The Furuno IC-116 is a high-performance, omni-directional antenna designed for use with the FELCOM 16 Mobile Earth Station. This antenna is a critical component for vessels utilizing the Inmarsat-C network for Ship Security Alert Systems (SSAS) and general data reporting.

Designed for 24/7 operation in the harshest sea conditions, the IC-116 features a maintenance-free design with no moving parts. Its helical element is enclosed in a high-impact, UV-resistant radome, ensuring consistent satellite connectivity even during heavy vessel motion or extreme weather.

TECHNICAL SPECIFICATIONS

-- Model: Furuno IC-116

-- System Compatibility: Furuno FELCOM 16 (SSAS / Inmarsat-C)

-- Antenna Type: Omni-directional Helical

-- TX Frequency: 1626.5 MHz to 1646.5 MHz

-- RX Frequency: 1530.0 MHz to 1545.0 MHz

-- G/T Ratio: -23 dB/K (at 5-degree elevation)

-- Power Source: Supplied via the communication terminal

-- Operating Temperature: -35C to +70C

-- Waterproofing: IP56 (Weatherproof Radome)

-- Dimensions: 156 mm (Diameter) x 230 mm (Height)

-- Mounting: 1-inch pipe mount (Standard Marine)

KEY FEATURES & APPLICATIONS

-- SSAS Optimized: Designed to provide reliable data links for Ship Security Alert Systems, ensuring that distress signals are transmitted instantly without the need for antenna tracking.

-- Durable Construction: Built with a reinforced radome that resists the corrosive effects of salt air, exhaust fumes, and intense sunlight.

-- Easy Installation: Uses a single coaxial cable connection for both power and signal, simplifying the replacement process for ship technicians.

-- Wide Sky Coverage: The omni-directional pattern ensures a stable satellite link regardless of the ship's heading or rolling motion in rough seas.

-- Low Maintenance: The lack of internal motors or gears makes the IC-116 one of the most reliable satellite antennas in Furuno’s legacy lineup.

TYPICAL CONDITION (USED/REFURBISHED)

In the Bhavnagar market, IC-116 units are carefully inspected for any physical damage to the outer casing that could lead to water ingress. Refurbished units undergo signal loop-back testing to verify that the internal amplifiers are providing the correct gain for both transmission and reception. We ensure the base threads and the N-Type connector are in excellent condition for a secure installation.

COMPATIBLE BRAND MODELS:

Furuno (FELCOM 16, FELCOM 15, FELCOM 18, IC-115, IC-118, IC-216), JRC (JUE-85, JUE-95, NAF-742), Thrane & Thrane / Sailor (TT-3005M, TT-3026, TT-3027), Cobham (Sailor 6110, 6120 SSAS), Samyung (SN-100), Skanti (Scansat-700), Nera (WorldClass C).
