PRE OWNED FURUNO IC-118 FURUNO IC-118 MARINE ANTENA

The Furuno IC-118 is the primary antenna unit for the modern FELCOM 18 Inmarsat-C Mobile Earth Station. It is a highly sought-after component in the ship-recycling hubs of Bhavnagar because it supports the latest GMDSS, SSAS, and LRIT requirements, making it an essential upgrade or replacement for ocean-going vessels.

FURUNO IC-118 ANTENNA UNIT (FOR FELCOM 18)

PRODUCT OVERVIEW

The Furuno IC-118 is a high-gain, omni-directional helical antenna designed for seamless two-way satellite communication. As the outdoor unit for the FELCOM 18 system, it handles all Inmarsat-C functions, including telex, email, and Enhanced Group Calling (EGC).

Unlike earlier models, the IC-118 is optimized for modern maritime data standards, including Long-Range Identification and Tracking (LRIT) and Ship Security Alert System (SSAS). Its radome is designed to maintain a stable satellite link even at low elevation angles (down to 5 degrees), ensuring reliable communication in high-latitude regions or during heavy vessel rolling.

TECHNICAL SPECIFICATIONS

-- Model: Furuno IC-118

-- System Compatibility: Furuno FELCOM 18 (Inmarsat-C)

-- Antenna Type: Omni-directional Helical

-- TX Frequency: 1626.5 MHz to 1646.5 MHz

-- RX Frequency: 1537.0 MHz to 1544.2 MHz

-- G/T Ratio: -23.0 dB/K (at 5-degree elevation)

-- Output Power: 12 to 16 dBW (at 5-degree elevation)

-- Operating Temperature: -35C to +55C (Storage up to +70C)

-- Waterproofing: IP56 (Standard for exposed marine equipment)

-- Weight: 1.4 kg (Compact and lightweight)

-- Mounting: Standard 1-inch (IPS) pipe mount

KEY FEATURES & APPLICATIONS

-- Full GMDSS Compliance: When integrated with the FELCOM 18 terminal, it meets all IMO requirements for safety and distress communication in Sea Areas A1, A2, and A3.

-- LRIT & SSAS Ready: Specifically designed to handle the frequent data reporting required for tracking and security without manual intervention.

-- No Tracking Required: The omni-directional design means there are no internal motors to wear out or gears to seize, providing maximum reliability for years.

-- Superior Signal Gain: Features a high-performance internal LNA (Low Noise Amplifier) that ensures clear reception of SafetyNET and FleetNET messages.

-- Interchangeable Base: Uses the same mounting footprint as the IC-115, allowing for a fast and simple upgrade from FELCOM 15 systems.

-- Single Cable Connection: Power and high-frequency data are carried over a single 50-ohm coaxial cable, reducing installation complexity.

TYPICAL CONDITION (USED/REFURBISHED)

In our Bhavnagar testing facility, each IC-118 is subjected to a comprehensive "Link Test." We check the transmission (TX) power and reception (RX) sensitivity to ensure the unit can successfully "log in" to the Inmarsat satellite. The radome is checked for UV degradation or hairline cracks, and the N-type connector is verified for zero moisture ingress to prevent signal loss.

COMPATIBLE BRAND MODELS:

Furuno (FELCOM 18, FELCOM 19, FELCOM 15, IC-115, IC-116, IC-119, IC-218), JRC (JUE-85, JUE-87, NAF-742), Thrane & Thrane / Sailor (TT-3027C, TT-3026, Sailor 6110), Cobham (Sailor 6120, 6130), Samyung (SN-100), Skanti (Scansat-701), Nera (WorldClass C).
