PRE OWNED FURUNO IC-119 FURUNO IC-119 MARINE ANTENA

PRODUCT OVERVIEW

The Furuno IC-119 is an advanced Inmarsat Mini-C antenna designed for the FELCOM 19 Mobile Earth Station. This unit is uniquely engineered as a "Black-Box" ADE (Above Deck Equipment), meaning the critical communication electronics are housed directly inside the antenna radome.

It provides seamless support for Long-Range Identification and Tracking (LRIT), Ship Security Alert Systems (SSAS), and general messaging (E-mail, Telex, and Data Polling). Its omni-directional helical design ensures constant satellite contact without the need for complex mechanical tracking, making it ideal for the extreme vibration and motion of commercial shipping.

TECHNICAL SPECIFICATIONS

-- Model: Furuno IC-119

-- System Compatibility: Furuno FELCOM 19 (Mini-C)

-- Antenna Type: Omni-directional Helical (Integrated GPS/Inmarsat-C)

-- TX Frequency: 1626.5 MHz to 1646.5 MHz

-- RX Frequency: 1537.0 MHz to 1544.2 MHz

-- Minimum G/T: -23.7 dB/K (at 5-degree elevation)

-- Output Power: 7 to 16 dBW (at 5-degree elevation)

-- Power Supply: 12-24 VDC (Supplied via Communication Unit IC-219)

-- Operating Temperature: -35C to +55C (Standard Marine)

-- Waterproofing: IP56 (Weatherproof Radome)

-- Weight: 1.4 kg (Compact design)

-- Mounting: Standard 1-inch pipe mount

KEY FEATURES & APPLICATIONS

-- Integrated GPS Receiver: The IC-119 features a built-in GPS antenna and receiver, allowing the system to provide high-accuracy position reporting for LRIT and SSAS without external GPS input.

-- Mini-C Efficiency: Specifically optimized for the Mini-C network, providing lower power consumption while maintaining robust data transmission for polling and messaging.

-- LRIT & SSAS Compliance: Fully meets IMO requirements for Long-Range Identification and Tracking and Ship Security Alerting when paired with the IC-219 Communication Unit.

-- Simplified Installation: Only requires a single coaxial cable to handle power, satellite data, and GPS signals, significantly reducing installation time and potential failure points.

-- Extreme Durability: The radome is constructed from UV-resistant, high-impact thermoplastic to survive years of exposure to salt-spray, diesel fumes, and tropical sunlight.

TYPICAL CONDITION (USED/REFURBISHED)

When we supply refurbished IC-119 units from Bhavnagar, we prioritize testing the "internal modem" functionality. Unlike older antennas, the IC-119 is more electronic than mechanical. We verify that the GPS cold-starts correctly and that the signal-to-noise ratio (SNR) for Inmarsat-C reception is within factory limits. We also ensure the connector base is completely free of water damage or oxidation.

COMPATIBLE BRAND MODELS:

Furuno (FELCOM 19, FELCOM 18, IC-219, IC-118, IC-115, IC-116), JRC (JUE-87, JUE-95, NAF-742), Thrane & Thrane / Sailor (TT-3027C, TT-3026, Sailor 6110, 6120), Cobham (Sailor 6110, 6130), Samyung (SN-100), Skanti (Scansat-701), Nera (WorldClass C).
