PRE OWNED FURUNO NAVIPILOT 300 FURUNO NAVIPILOT 300 MARINE AUTOPILOT

PRODUCT OVERVIEW

The NAVpilot-300 is a versatile autopilot that features Furuno’s unique self-learning and adaptive software. From the first voyage, the pilot begins to learn the vessel's steering characteristics, automatically adjusting for speed, trim, tide, and wind. The system is famous for its Gesture Controller (GC-001), a handheld Bluetooth remote that allows the captain to change the boat's heading simply by pointing the remote in the desired direction.

Equipped with Fantum Feedback™, the NAVpilot-300 eliminates the need for a physical rudder reference unit on outboard-powered boats. This significantly reduces installation time and complexity while still providing precise course control from slow trolling speeds to high-speed cruising. Its 4.1-inch color display is sharp and easy to read, even in direct sunlight.

TECHNICAL SPECIFICATIONS

-- Model: NAVpilot-300 (Control Unit: FAP-3011)

-- Processor Unit: FAP-3012

-- Remote Control: GC-001 Gesture Controller (Bluetooth)

-- Display: 4.1-inch Color TFT LCD (320 x 240 pixels)

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 0.22A (Processor) / 0.29A (Control Unit)

-- Steering Modes: STBY, Auto, Dodge, Turn, NFU, Navigation, SABIKI™, FishHunter™

-- Network: 1x NMEA 2000 (CAN bus)

-- Drive Capacity: 10A continuous (20A for 5 seconds)

-- Waterproofing: IP55 (Processor) / IP56 (Control Unit) / IP67 (Remote)

-- Range: Bluetooth connectivity up to 10 meters

KEY FEATURES & APPLICATIONS

-- Gesture Control: The "Point and Shoot" remote allows for effortless course changes from anywhere on the boat, perfect for single-handed operation or when moving away from the helm.

-- SABIKI™ Mode: Specifically designed for fishing, this mode maintains the vessel's heading while drifting astern, allowing the angler to focus entirely on jigging or bottom fishing.

-- Fantum Feedback™: Uses advanced software algorithms instead of a mechanical rudder sensor, clearing the way for a cleaner, more reliable installation on outboard vessels.

-- FishHunter™ Patterns: Provides pre-programmed steering maneuvers such as Zig-Zag, Orbit, Figure-Eight, and Spiral around a sonar or radar target or an MOB point.

-- Safe Helm & Power Assist: When used with the optional FPS8 Power Steering Module, it allows for temporary manual steering and provides speed-sensitive power steering.

-- Smart Networking: Fully NMEA 2000 certified, allowing it to be controlled directly from NavNet TZtouch, TZtouch2, and GP1871F/1971F chartplotters.

TYPICAL CONDITION (USED/REFURBISHED)

When we test refurbished NAVpilot-300 units from Alang, we pay close attention to the Bluetooth pairing between the FAP-3012 processor and the GC-001 remote. We verify that the NMEA 2000 backbone communication is stable and that the processor drive circuit can handle the continuous current required for hydraulic pumps. The LCD is inspected for any pixel degradation, and the "Fantum Feedback" calibration is reset to ensure a fresh setup for the next vessel.

COMPATIBLE BRAND MODELS:Furuno (NAVpilot-711C, NAVpilot-700, PG-700, SC-33, SCX-20, GP-33, GP-1871F, GP-1971F), Suzuki (Precision Control SPC 2.0), Yamaha (Helm Master), Yanmar (8LV / VC10), Volvo Penta (IPS), Seastar (Optimus 360), Garmin (GHP Reactor), Simrad (AP44, NAC-2).
