PRE OWNED ICOM MA - 500TR ICOM MA-500TR MARINE AIS

PRODUCT DATA SHEET: ICOM MA-500TR CLASS-B AIS (USED/REFURBISHED)

PRODUCT OVERVIEW

The Icom MA-500TR is a compact, standalone Class-B AIS transponder designed for non-SOLAS vessels such as pleasure craft, fishing boats, and small workboats. Unlike many "black box" AIS units that require an external plotter, the MA-500TR features its own dedicated high-contrast dot-matrix display. This allows for independent traffic monitoring and collision-risk management. It is highly regarded in the used market for its simple interface, dual-channel reception, and seamless integration with Icom VHF radios.

+2

TECHNICAL SPECIFICATIONS

Model: Icom MA-500TR

AIS Class: Class-B Transponder

Display: 128 x 128 pixel full dot-matrix LCD with adjustable backlight

Output Power: 2 W (Typical for Class-B)

Frequency Range: 156.025 MHz to 162.025 MHz (Dual channel receive)

GPS Receiver: External MXG-5000 (included in most used sets)

Waypoints: 100 memory slots with 10-character naming

Interfaces: 3-line NMEA 0183 (Input/Output) via 15-pin D-SUB

Waterproofing: IPX7 (Submersible 1m for 30 mins, excluding connectors)

Power Supply: 12 VDC nominal (9.6 V to 15.6 V)

Weight: Approx. 1.0 kg (2.2 lbs)

KEY FEATURES & APPLICATIONS

Standalone Operation: Does not require a chartplotter to function; the internal display shows a "Radar-style" plotter view, target lists, and danger lists.

Collision-Risk Management: Automatically calculates CPA (Closest Point of Approach) and TCPA (Time to CPA). The unit blinks and beeps when a vessel enters your safety parameters.

+1

Direct DSC Calling: When connected to compatible Icom VHF radios (e.g., M506, M424, M400BB), you can select an AIS target on the screen and initiate an individual DSC call instantly without manual MMSI entry.

Target & Danger Lists: Features a "Danger List" that prioritizes the most immediate collision threats, allowing the navigator to focus on the most critical traffic.

MOB (Man Overboard) Button: A dedicated button allows the operator to instantly mark the current GPS position as a waypoint for emergency return.

External Alarm Output: Can be connected to an external horn or buzzer on the deck or flybridge to ensure collision alerts are heard in loud environments.

Stealth Mode: Allows the user to stop transmitting vessel data (for privacy or fishing) while still receiving AIS data from surrounding traffic.

TYPICAL CONDITION (USED/REFURBISHED)

Common Issue: In used units, verify the condition of the 15-pin NMEA cable; because it is a proprietary D-SUB connector, replacements can be harder to find than standard wires.

Refurbishment: Often sold with a new MXG-5000 GPS antenna, as the original cables are frequently cut during removal from the previous vessel.
