PRE OWNED JRC JAN-901B JRC JAN-901B MARINE ECDIS

The JRC JAN-901B is a high-performance Electronic Chart Display and Information System (ECDIS) known for its rugged reliability and large-format viewing area. In the Bhavnagar and Alang markets, it is a highly requested model for deep-sea vessels due to its powerful processor and seamless integration with JRC’s high-end radar systems.

JRC JAN-901B MARINE ECDIS

PRODUCT OVERVIEW

The JRC JAN-901B is an IMO-compliant navigation system featuring a large 23.1-inch high-resolution display. It is designed to handle the intense processing requirements of modern digital navigation, including high-speed chart redrawing and simultaneous display of AIS and ARPA targets. The system is built around a modular architecture, with a dedicated central processing unit (CPU) and a robust keyboard/trackball control unit that allows for precise operation even in heavy seas.

The JAN-901B is particularly famous for its user-friendly interface that mimics JRC’s radar controls, making it easy for bridge officers to transition between systems. It supports a wide range of chart formats, including S-57, S-63, and C-MAP, and offers a comprehensive suite of route planning and monitoring tools that ensure the vessel stays within safe navigational parameters at all times.

TECHNICAL SPECIFICATIONS

-- Model: JAN-901B

-- Manufacturer: JRC (Japan Radio Co., Ltd.)

-- Display Unit: 23.1-inch High-Resolution Color LCD (NWZ-173)

-- Resolution: 1600 x 1200 Pixels (UXGA)

-- Processor Unit: NDC-1444 (Central Control Unit)

-- Control Unit: NCE-5163 (Keyboard with Trackball)

-- Chart Formats: S-57 Ed. 3 (ENC), S-63 (Encrypted), C-MAP, ARCS

-- Interfaces: 8x NMEA 0183 (Inputs), 4x NMEA 0183 (Outputs), LAN (Ethernet)

-- Power Supply: 100-115V / 200-230V AC

-- Power Consumption: Approximately 200 VA

-- Data Storage: High-reliability internal hard drive for charts and logs

-- Compliance: IMO MSC.232(82), IEC 61174, IEC 61162, IEC 62288

KEY FEATURES & APPLICATIONS

-- Large 23.1-inch Workspace: The UXGA resolution provides an expansive view of the chart, allowing for detailed route monitoring without sacrificing the visibility of essential navigational data.

-- Advanced Radar Overlay: When interfaced with JRC JMA-series radars, the system overlays live radar echoes onto the chart, providing a complete tactical overview for collision avoidance.

-- Comprehensive Route Planning: Features an intuitive route editor that allows officers to create, check, and optimize voyage plans with automatic safety contour verification.

-- Target Tracking (TT) & AIS: Capable of displaying and tracking a large number of ARPA and AIS targets simultaneously, complete with CPA/TCPA alarms for enhanced safety.

-- Multi-Display Capability: Can be networked to multiple stations (Master/Backup) to support paperless navigation and ensure redundancy as per SOLAS regulations.

-- Standardized Operation: The control layout and menu structure are standardized across JRC’s navigation line, reducing the need for extensive crew training during equipment upgrades.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished JAN-901B units from the Alang yards are put through a rigorous technical inspection. We focus on the NDC-1444 CPU, ensuring the internal power supply and cooling fans are in peak condition. The NWZ-173 monitor is tested for backlight intensity and color accuracy. We also perform a comprehensive check of the NCE-5163 control unit, ensuring the trackball is smooth and all keyboard functions respond instantly. Every system is updated with the latest stable firmware and factory-reset for immediate deployment.

COMPATIBLE BRAND MODELS:

JRC JAN-901B, JRC JAN-701B, JRC JAN-9201, JRC JMA-9900 Radar, JRC JMA-9100 Radar, Furuno FMD-3200, Furuno FMD-3300, Sperry Marine VisionMaster FT, Tokyo Keiki EC-8100, Danelec DM-800.
