PRE OWNED JRC JLR-10 JRC JLR-10 MARINE GPS

The JRC JLR-10 uses a sophisticated three-antenna GPS system to calculate the vessel's heading with extreme precision (typically within 0.5°). Unlike a magnetic compass, it is not affected by the ship's magnetic field or "deviation," and unlike a gyrocompass, it does not require a long settling time or expensive annual overhauls. This makes it an ideal primary heading sensor for Radars, ECDIS, AIS, and Autopilots on commercial vessels.

The system consists of a compact, ruggedized antenna array and a dedicated processor/display unit. Beyond heading, the JLR-10 provides high-accuracy GPS position data and 3-axis motion sensing. This motion data is critical for stabilizing sonar and echo sounder images in rough seas, as it can compensate for the ship’s heave and pitch. Its robust NMEA 0183 and high-speed data outputs ensure it can integrate into any modern bridge suite.

TECHNICAL SPECIFICATIONS

-- Model: JLR-10

-- Manufacturer: JRC (Japan Radio Co., Ltd.)

-- Heading Accuracy: 0.5° RMS

-- Heading Resolution: 0.1°

-- Position Accuracy: GPS: 10m (95%)

-- Settling Time: Less than 2 minutes (typical)

-- Follow-up Speed: 25° per second

-- Motion Sensing: Roll, Pitch, and Heave data output

-- Display: Digital LCD with backlighting

-- Interfaces: NMEA 0183 (Multiple ports), AD-10 (For older Radars)

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: Approx. 15 W

-- Operating Temperature: -25°C to +70°C (Antenna unit)

KEY FEATURES & APPLICATIONS

-- Maintenance-Free Operation: With no mechanical gyros or rotating parts, the JLR-10 eliminates the high costs associated with traditional gyrocompass servicing and sphere replacements.

-- High-Speed Heading Tracking: Capable of tracking rapid course changes (up to 25°/sec), ensuring that Radars in "North-Up" mode and AIS targets remain stable during sharp turns.

-- Tri-Antenna System: The unique three-antenna configuration provides superior heading stability compared to dual-antenna models, especially in areas with significant signal multi-path interference.

-- 3-Axis Motion Compensation: Outputs real-time heave, roll, and pitch data, which is essential for multi-beam echo sounders and sub-bottom profilers to maintain an accurate seabed image.

-- Universal Bridge Compatibility: Supports NMEA 0183 and the older Furuno/JRC AD-10 format, allowing it to provide heading data to both modern digital systems and legacy "green screen" Radars.

-- Fast Start-Up: Provides a stable heading fix in less than 2 minutes, allowing the vessel to get underway much faster than ships waiting for a traditional gyro to settle (which can take hours).

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished JLR-10 units from the Alang yards undergo a strict technical validation. We focus on the Antenna Array, checking for any moisture ingress or UV damage to the radomes. The internal GPS modules are tested for signal-to-noise ratio to ensure a fast, stable heading lock. We also verify the NMEA output buffers to ensure they are providing clean heading strings (HDT/HDM) to external equipment. Every unit is factory-reset and provided with a detailed test report from our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

JRC JLR-10, JRC JLR-20, JRC JLR-21, Furuno SC-50, Furuno SC-60, Furuno SC-110, Simrad HS70, Simrad GN70, Sperry Marine NAVIGAT, Tokyo Keiki G-1.
