PRE OWNED KODEN KAT-100 KODEN KAT 100 USED MARINE AIS

KODEN KAT-100 CLASS A AIS SYSTEM

PRODUCT OVERVIEW

The Koden KAT-100 features a high-contrast 3.5-inch monochrome LCD display and is fully compliant with IMO and IEC standards for Class A AIS. Unlike Class B units, the KAT-100 transmits at a powerful 12.5 Watts and utilizes SOTDMA technology to prioritize position reporting in high-density traffic areas. It is designed to provide real-time situational awareness by displaying the position, speed, heading, and ship-specific information of all AIS-equipped targets within VHF range.

The system is a "self-contained" unit, integrating the VHF transmitter, dual TDMA receivers, a 70-channel DSC receiver, and a high-sensitivity GPS sensor within a single rugged housing. It is engineered to feed precise target data to the ship's Radar and ECDIS via NMEA 0183 or NMEA 2000. Its tactical numeric keypad and dedicated "Target List" allow the officer of the watch to quickly assess collision risks and communicate with nearby vessels via the integrated pilot plug or VHF.

TECHNICAL SPECIFICATIONS

-- Model: KAT-100

-- Manufacturer: Koden Electronics Co., Ltd. (Japan)

-- Display: 3.5-inch Monochrome Backlit LCD

-- AIS Class: Class A (SOLAS Compliant)

-- Frequency Range: 156.025 to 162.025 MHz

-- Power Output: 12.5 Watts / 2 Watts

-- Receivers: 2x TDMA, 1x DSC (Channel 70)

-- Interfaces: 3x NMEA 0183 Outputs, 1x NMEA 2000, RS-232, Pilot Plug

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 10 Watts (Average)

-- Waterproofing: IPX6 (Front Panel)

-- Compliance: IMO MSC.74(69), IEC 61993-2, Wheelmark Certified

KEY FEATURES & APPLICATIONS

-- SOLAS Class A Compliance: Meets all international requirements for mandatory AIS carriage on commercial ships over 300 GT, ensuring full regulatory approval for global trade.

-- SOTDMA Technology: Ensures priority transmission of the vessel's data in busy ports like Mumbai or Kandla, where VHF channel congestion is common.

-- Integrated Pilot Plug: Features a built-in Pilot Plug on the front panel, allowing maritime pilots to quickly connect their navigation laptops for precise berthing.

-- Enhanced Situation Awareness: Provides a clear list of nearby targets with CPA (Closest Point of Approach) and TCPA (Time to CPA) alarms to prevent collisions.

-- NMEA 2000 Ready: Includes high-speed NMEA 2000 connectivity for seamless integration with modern multi-function displays (MFDs) and bridge networks.

-- "Silent Mode" Capability: Allows the vessel to stop broadcasting its own position during security-sensitive transits while still receiving data from other ships.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished Koden KAT-100 units from the Alang recycling yards undergo a strict "RF Performance Audit." We focus on the VHF Transceiver power output, ensuring a stable 12.5W signal for long-range reporting. The tactile membrane keypad is tested for responsiveness, and the LCD backlight is checked for uniformity. We also perform a software reset to ensure the MMSI and ship data can be re-programmed for your specific vessel. Every unit is factory-reset at our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Koden KAT-100, Furuno FA-150, Furuno FA-170, JRC JHS-182, JRC JHS-183, ComNav Voyager X3, Samyung SI-30, McMurdo Smartfind M2, Saab R4, Simrad AI80.
