PREOWNED FURUNO FAR - 2827 FURUNO FAR-2827 RADAR

The Furuno FAR-2827 is a 25 kW X-band marine radar designed for SOLAS-class vessels, featuring a 23.1-inch high-resolution color LCD, superior target detection (MLQ), and ARPA capabilities. It meets IMO standards for ships >10,000 GT, providing precise navigation, AIS integration for up to 1,000 targets, and selectable 6' or 8' antennas.

Key Specifications of the Furuno FAR-2827

Radar Type: X-Band

Power Output: 25 kW (nominal), with some listings noting 30 kW peak power

Display: 23.1-inch Color LCD (1600 x 1280 pixels)

Range Scales: 0.0625 to 96 nautical miles

Antenna Options: 6.5 ft or 8 ft Open Array

Rotation: 24 RPM (typical)

Target Tracking: Built-in ARPA (tracks up to 100 targets) and AIS (up to 1,000 targets)

Features: Echo averaging, echo stretch, and multi-level quantization (MLQ)

Compliance: IMO/SOLAS Standards

Components

Display: MU-231 (23.1" Color LCD)

Processor: RPU-013

Control Unit: RCU-014 (Full keyboard or trackball)

Antenna: RSB-096 (24 RPM)
