PRE OWNED NIONGLU DS-2008 NINGLU DS-2008 MARINE ECHO SOUNDER

The Ninglu DS-2008 is a MED-certified echo sounder that provides mariners with a stable and high-definition view of the seabed. It features a 10.4-inch high-resolution color TFT LCD that displays digital depth and a historical echogram simultaneously. One of the system's strongest advantages is its dual-frequency capability, supporting both 50 kHz and 200 kHz transducers, which allows for precise sounding in both shallow harbors and deep-sea environments.

Designed to meet the latest SOLAS and IMO regulations, the DS-2008 includes a high-capacity internal memory that records up to 20 hours of depth data. This eliminated the need for traditional paper recorders while ensuring full compliance for port state inspections. Its "Black Box" architecture and flexible mounting options make it an ideal choice for bridge retrofits where visibility and reliability are paramount.

TECHNICAL SPECIFICATIONS

-- Model: DS-2008

-- Manufacturer: Ninglu Technology (China)

-- Display: 10.4-inch Color TFT LCD (800 x 600 pixels)

-- Frequency: Dual Frequency (50 kHz and 200 kHz supported)

-- Output Power: 500 W (RMS)

-- Depth Range: 0.4 meters to 800 meters

-- Accuracy: +/- 1.0% of range

-- Data Memory: 20 hours of internal depth history recording

-- Interfaces: 2x NMEA 0183 Outputs (DPT, DBT), 1x NMEA Input, VGA Output

-- Supply Voltage: 24V DC (with optional 110/220V AC adapter)

-- Power Consumption: Approximately 30 W

-- Compliance: IMO MSC.74(69) Annex 4, MED Certified (Wheelmark)

KEY FEATURES & APPLICATIONS

-- Paperless Data Logging: Features a high-capacity rolling memory that stores 20 hours of depth, time, and position data. This data can be reviewed on-screen at any time to verify past navigational safety.

-- High-Resolution Color Display: The 10.4-inch screen provides excellent visibility with multiple color palettes (Day/Night modes) to protect the bridge team's vision during night watch.

-- Advanced Signal Processing: Utilizes specialized filtering technology to distinguish between the actual seabed and interference caused by ship noise or aeration.

-- Draft and Trim Correction: Allows for easy manual input of the vessel's current draught to accurately display either "Depth Below Keel" or "Depth Below Surface."

-- Multiple Alarms: Equipped with programmable shallow-water and deep-water alarms to provide immediate audio-visual warnings when the vessel enters hazardous zones.

-- VGA Output for Bridge Integration: Includes a standard VGA port to repeat the echo sounder's display on a secondary large-screen monitor or at a separate workstation.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished Ninglu DS-2008 units from the Alang yards undergo a thorough multi-point inspection. We focus on the transceiver board for output stability and receiver sensitivity at both 50 kHz and 200 kHz. The 10.4-inch LCD is checked for backlight consistency and pixel health. We also verify the NMEA 0183 data ports for stable communication with VDR and ECDIS systems. Every unit is factory-reset and provided with a detailed performance report from our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

Ninglu DS-2008, Ninglu DS-2006, Furuno FE-700, Furuno FE-800, JRC JFE-380, JRC JFE-680, Consilium E1, Consilium E2, Skipper GDS-101, Sperry Marine ES-5100, Raytheon Anschütz GDS-102.
