PRE OWNED ONWA KP-32 ONWA KP-32 MARINE GPS

the ONWA KP-32 is a versatile and cost-effective GPS/SBAS navigator that has become a staple in the Bhavnagar and Alang regions. It is highly regarded as a reliable alternative to the Furuno GP-32, offering identical mounting dimensions and a familiar interface, which makes it an ideal choice for quick retrofits on fishing vessels and small-to-medium commercial ships.

ONWA KP-32 GPS/SBAS NAVIGATOR

PRODUCT OVERVIEW

The ONWA KP-32 is an advanced GPS navigator featuring a 4.5-inch high-contrast monochrome LCD. Designed for ease of use, it utilizes a high-sensitivity 12-channel parallel receiver and SBAS (WAAS/EGNOS/MSAS) technology to provide position accuracy within 3 meters. Its compact and waterproof design allows it to be installed in open cockpits or integrated into crowded bridge consoles.

The system is highly functional, storing up to 999 waypoints and 50 routes. It provides a variety of display modes, including a Plotter screen for track visualization and a "Highway" mode that offers a 3D perspective of the vessel’s course. Its robust NMEA 0183 connectivity ensures it can provide precise position, speed, and heading data to AIS systems, Radars, and Autopilots, making it a central component for safe coastal navigation.

TECHNICAL SPECIFICATIONS

-- Model: KP-32

-- Manufacturer: ONWA Marine Electronics (Hong Kong)

-- Display: 4.5-inch Monochrome Silver Bright LCD

-- Resolution: 120 x 64 Pixels

-- Receiver Type: 12-channel parallel, SBAS ready

-- Position Accuracy: GPS: 15m (95%), SBAS: 3m (95%)

-- Storage: 999 Waypoints, 8,000 Track Points, 50 Routes

-- Interfaces: 1x NMEA 0183 Output (Ver 2.0), 1x RS-232C

-- Supply Voltage: 12V to 24V DC

-- Power Consumption: 240 mA (at 12V)

-- Waterproofing: IPX5 (Display Unit)

-- Alarms: Arrival, Anchor Watch, XTE, Speed, Time, Trip

KEY FEATURES & APPLICATIONS

-- High-Sensitivity SBAS Receiver: Uses satellite-based correction signals to provide precision navigation, ensuring the vessel stays on its intended track even in narrow harbor entries.

-- Standardized Mounting: The housing is designed to be a "drop-in" replacement for the Furuno GP-32, allowing ship owners to upgrade or replace units without modifying their existing console cutouts.

-- Versatile Display Modes: Includes Plotter, Highway, Steering, Nav Data, and Satellite Monitor, all accessible via a simple menu structure.

-- Tactile "Direct Keys": Features dedicated physical buttons for "MARK" and "GOTO," allowing the operator to save locations or initiate navigation instantly in emergency situations.

-- Robust Data Output: Features reliable NMEA 0183 output strings (GPRMC, GPGGA, GPVTG) to synchronize the ship’s position across the entire electronics suite.

-- Non-Volatile Memory: Ensures that all routes and waypoints are safely stored without the need for a battery backup, protecting data during long periods of power-down.

TYPICAL CONDITION (USED/REFURBISHED)

Our refurbished ONWA KP-32 units from the local maritime sector are put through a rigorous technical overhaul. We focus on the LCD contrast, ensuring the screen is perfectly readable in bright sunlight. The keypad membrane is checked for physical wear and responsiveness. We also verify the NMEA 0183 output to ensure it is communicating accurately with AIS and Radar systems. Every unit is supplied with a high-gain GPS antenna and is factory-reset at our Bhavnagar facility.

COMPATIBLE BRAND MODELS:

ONWA KP-32, Furuno GP-32, Furuno GP-31, Samyung GP-280, Matsutec HP-32, Koden KGP-913, Garmin GPS 152, JRC JNAV-500.
