PRE OWNED RAY MARINE RE-120 RAYMARINE RE - 120 MARINE RADAR

PRODUCT DATA SHEET: RAYMARINE E120 (CLASSIC) MFD

PRODUCT OVERVIEW

The Raymarine E120 is a 12.1-inch Multi-Function Display designed to be the "brain" of a vessel's navigation system. Part of the E-Series Classic line, it was one of the first displays to offer seamless integration of Radar, Chartplotter, Fishfinder, and Video on a single, high-resolution screen. Known for its "Ultra-Bright" sunlight-viewable display and rugged construction, the E120 remains a top choice for boaters looking for a reliable, large-format networked display on the secondary market.

TECHNICAL SPECIFICATIONS

Model: Raymarine E120 (E02013)

Display: 12.1" TFT LCD (Sunlight Viewable)

Resolution: 800 x 600 pixels (SVGA)

Processor: High-speed 32-bit CPU with hardware graphics accelerator

Cartography: Navionics Gold, Platinum, or Platinum Plus (CompactFlash)

Networking: SeaTalk, SeaTalk hs (Ethernet), SeaTalk 2, and NMEA 0183/2000

Video Inputs: 4x Composite Video inputs (for engine room or deck cameras)

Power Supply: 12/24 VDC (10.7 V to 32 V)

Waterproofing: IPX6 (Standard for bridge and open cockpit mounting)

Mounting: Bracket (Trunnion) or Flush mount

KEY FEATURES & APPLICATIONS

SeaTalk hs Networking: Allows for high-speed data transfer between multiple E-Series displays. Radar and Fishfinder data can be shared across the network with virtually no lag.

Hybrid Integration: Supports a wide range of peripherals, including Analog Radomes and Open Arrays, DSM30/300 Sonar Modules, and AIS receivers.

Radar/Chart Overlay: Provides the ability to overlay radar echoes directly onto the electronic chart, aiding in the immediate identification of buoys and landmasses.

Video Monitoring: With four dedicated video inputs, the E120 can act as an onboard CCTV monitor for engine rooms, docking cameras, or thermal imaging (FLIR).

SmartRoute™ Technology: Automatically creates a route from your existing track history, simplifying the planning of frequent voyages.

Customizable Data Bar: Users can choose which engine, environment, or navigation data points are visible on the side or bottom of the screen at all times.

TYPICAL CONDITION (USED/REFURBISHED)

Screen Maintenance: In used units, the anti-reflective coating is often checked for "delamination" (smearing). Many refurbished units have this coating polished or replaced for a clear finish.

Connectivity: Used units are prized as "drop-in" replacements for failed E120 heads, as they utilize the same cabling and cutouts as original installations.

Upgrade Path: While it is a legacy unit, it can still interface with modern AIS and NMEA 2000 sensors using Raymarine’s SeaTalk to SeaTalk ng converter kits.
