PRE OWNED SAILOR TT-3000SSAS SAILOR TT-3000SSAS

PRODUCT OVERVIEW

The Sailor TT-3000SSAS is a dedicated security and tracking terminal designed to meet all SOLAS XI-2/6 requirements. The heart of the system is the TT-3026M transceiver, which integrates the satellite antenna, the Inmarsat-C modem, and a 12-channel GPS receiver into a single, compact, and hermetically sealed radome.

Unlike standard communication systems, the TT-3000SSAS is built for covert alerting. When a security button is pressed on the bridge or in the engine room, the system sends a silent "Security Alert" to a predefined destination (Flag State, owner, or security center) without any visible or audible indication on the ship, ensuring the safety of the crew during a piracy or security event.

TECHNICAL SPECIFICATIONS

-- Model: Sailor TT-3026M (System: TT-3000SSA / SSAS)

-- Antenna Type: Omni-directional Helical (Integrated GPS/Inmarsat-C)

-- TX Frequency: 1626.5 MHz to 1646.5 MHz

-- RX Frequency: 1525.0 MHz to 1545.0 MHz

-- GPS Module: 12-Channel (15m RMS accuracy)

-- G/T Ratio: -23.7 dB/K (at 5-degree elevation)

-- E.I.R.P.: 7 dBW (at 5-degree elevation)

-- Power Source: 10.5V to 32V DC Floating

-- Power Consumption: 1.8W (Standby) / 23W (Transmit)

-- Operating Temp: -35C to +55C (Storage up to +80C)

-- IP Rating: IP68 (Fully waterproof and submersible)

-- Weight: 1.1 kg

KEY FEATURES & APPLICATIONS

-- Covert Security Alerting: Provides a silent, non-detectable alarm signal to shore-based authorities, meeting all ISPS code requirements for maritime security.

-- Stand-Alone Reliability: Functions completely independently of GMDSS or LRIT equipment, ensuring that a security alert can always be sent even if other systems are disabled.

-- Integrated GPS Reporting: Automatically includes highly accurate vessel coordinates, course, and speed in every alert and tracking report.

-- Web-Based Tracking: Can be configured for "Fire-and-Forget" position reporting, allowing owners to track their fleet globally via the Inmarsat network.

-- Rugged "Mini-C" Design: The TT-3026M radome is built to endure extreme weather, with high resistance to ice, heavy rain, and 100-knot winds.

-- Remote Configuration: Security destinations and reporting intervals can be updated remotely via satellite, requiring zero intervention from the crew on board.

TYPICAL CONDITION (USED/REFURBISHED)

When we supply refurbished TT-3000SSAS units from Bhavnagar, we focus heavily on "Covert Mode" testing. We verify that the transceiver responds correctly to button triggers and that the GPS maintains a solid lock. Because these units are often exposed to the harshest mast-top conditions, we meticulously inspect the radome for UV damage and ensure the multi-pin connector is professionally cleaned to prevent signal dropouts.

COMPATIBLE BRAND MODELS:Sailor / Thrane & Thrane (TT-3026M, TT-3026S, TT-3026C, TT-3000LRIT, Sailor 6120 SSAS, Sailor 6130, TT-3616D Interconnection Box), Furuno (FELCOM 16, FELCOM 19, IC-116, IC-119), JRC (JUE-95SA, NAF-253SA, JUE-85), Samyung (SN-100), Cobham (Sailor 6110, 6120), Skanti (Scansat-701).
