PRE OWNED SAILOR TT-3020C SAILOR TT-3020C MARINE ANTENA

PRODUCT OVERVIEW

The Sailor TT-3005M is an omni-directional maritime antenna specifically engineered for the Sailor TT-3020C and TT-3022D transceivers. Known for being one of the smallest Inmarsat-C antennas in the world, it provides a stable satellite link even at low elevation angles (down to -15 degrees), which is critical for vessels operating in rough seas or high-latitude regions.

The unit is completely maintenance-free with no internal moving parts. Its rugged, hermetically sealed radome is designed to withstand the most extreme weather conditions, including heavy icing, high-intensity rainfall, and hurricane-force winds. The integrated design simplifies installation by using a single coaxial cable for power, satellite data, and GPS signals.

TECHNICAL SPECIFICATIONS

-- Model: Sailor TT-3005M (Thrane & Thrane / Cobham)

-- System Compatibility: Sailor TT-3020C (GMDSS) / TT-3022D (Fishery)

-- Antenna Type: Omni-directional Helical (Integrated Inmarsat-C / GPS)

-- Transmit Frequency: 1626.5 MHz to 1660.5 MHz

-- Receive Frequency: 1525.0 MHz to 1559.0 MHz

-- GPS Frequency: 1575.42 MHz (L1 Band)

-- G/T Ratio: -23 dB/K (at 5-degree elevation)

-- E.I.R.P.: 14 dBW (+/- 2 dB at 5-degree elevation)

-- Elevation Angle: +90 to -15 degrees

-- Operating Temperature: -35C to +55C (Storage up to +80C)

-- Wind Resistance: Up to 200 km/hour (approx. 108 knots)

-- Waterproofing: Fully sealed radome (IPX6/IPX7 equivalent)

-- Dimensions: 178 mm (Height) x 122 mm (Diameter)

-- Weight: 0.9 kg (Ultra-lightweight)

-- Mounting: Standard 1-inch (25mm) tube/pipe mount

KEY FEATURES & APPLICATIONS

-- GMDSS Ready: Fully compliant with Inmarsat-C GMDSS specifications (CN114) for safety and distress communication in Sea Areas A1, A2, and A3.

-- Integrated GPS/SAT-C: Combines a high-sensitivity GPS element and a robust Inmarsat-C helical element, reducing the number of antennas required on the mast.

-- Smallest Footprint: Its compact size makes it the ideal choice for vessels with limited mast space or for quick replacement of older, bulkier antennas.

-- High Data Capacity: Approved for up to 32kb message size transmissions, allowing for graphics, pictures, and large data files.

-- Long Cable Support: Can be installed up to 100 meters away from the transceiver using high-quality low-loss coaxial cable (e.g., RG-214).

-- All-Weather Reliability: Designed to operate in high solar radiation and extreme precipitation (up to 100mm/hour) without loss of signal quality.

TYPICAL CONDITION (USED/REFURBISHED)

Refurbished TT-3005M units from the Alang/Bhavnagar shipyards are thoroughly tested for signal gain and power output. We check the internal LNA (Low Noise Amplifier) to ensure it meets the -23 dB/K G/T requirement for Inmarsat-C reception. Each unit is inspected for physical integrity of the radome seal and cleaned of any salt-air corrosion at the TNC connector to ensure a secure, moisture-free connection.

COMPATIBLE BRAND MODELS:Sailor / Thrane & Thrane (TT-3020C, TT-3022D, TT-3020B, TT-3005A, TT-3001B), Furuno (FELCOM 12, FELCOM 15, IC-112, IC-115), JRC (JUE-85, JUE-85C, NAF-741GM), Cobham (Sailor 6110), Samyung (SN-100), Skanti (Scansat-700), Nera (Saturn C).
