PRE OWNED SAILOR TT-3027LT SAILOR TT-3027LT MARINE ANTENA

PRODUCT OVERVIEW

The Sailor TT-3027LT is an advanced, fourth-generation Mini-C terminal that integrates the satellite antenna, transceiver, and a 12-channel GPS receiver into one compact radome. It is specifically optimized for LRIT operations, providing automatic, encrypted position reporting to shore-based authorities without requiring any manual intervention from the ship's crew.

As the core of the Sailor 6130 system, the TT-3027LT is known for its "plug-and-play" reliability. It uses a standard NMEA 2000 (CAN bus) interface for both power and data, making it much easier to install and network than legacy terminals. Its rugged construction and lack of moving parts make it an ideal "fit-and-forget" solution for compliance with IMO maritime security regulations.

TECHNICAL SPECIFICATIONS

-- Model: Sailor TT-3027LT (Part of Sailor 6130 System)

-- System Type: Dedicated Mini-C LRIT Terminal

-- Antenna Type: Omni-directional Helical (Integrated Inmarsat-C / GPS)

-- GPS Module: 12-channel receiver (15m RMS accuracy)

-- Data Rate: 600 bit/sec (Standard Inmarsat-C)

-- Tracking Frequency: Automatic reporting (standard 6-hour intervals)

-- Interface: NMEA 2000 (CAN bus) / ThraneLINK

-- Operating Voltage: 10.5V to 32V DC

-- Power Consumption: 1.8W (Standby) / 23W (Transmit)

-- Operating Temperature: -35C to +55C

-- Waterproofing: IP68 (Fully sealed and submersible)

-- Weight: 1.1 kg

-- Compass Safe Distance: 2.0 m

KEY FEATURES & APPLICATIONS

-- Full LRIT Compliance: Fully meets IMO performance standards for Long Range Identification and Tracking (MSC81/210).

-- ThraneLINK Integrated: Built on the modern ThraneLINK platform, allowing for easy software updates and diagnostics through a central Sailor control unit.

-- Automated Position Logging: Stores up to 10,000 positions locally, ensuring a complete tracking history even if the satellite link is temporarily obstructed.

-- No Crew Interface Required: Designed for autonomous operation; once powered, it manages all login and reporting tasks automatically.

-- Ruggedized EME: The UV-stabilized radome is designed to withstand 100-knot winds and heavy icing, ensuring continuous operation in extreme Sea Area A3 conditions.

-- Remote Polling: Supports remote requests from flag states for immediate position updates or changes to the reporting schedule.

TYPICAL CONDITION (USED/REFURBISHED)

Refurbished TT-3027LT units from the Alang yards are tested for NMEA 2000 connectivity and GPS lock-on speed. We verify that the "ISN" (Inmarsat Serial Number) is clear and ready for re-registration. The radome is checked for structural integrity, and the multi-pin connector is inspected to ensure it is free from salt-air oxidation, guaranteeing a stable connection once mounted on the mast.

COMPATIBLE BRAND MODELS:

Sailor / Thrane & Thrane (TT-3027C GMDSS, TT-3027D SSAS, Sailor 6110, Sailor 6120, Sailor 6130, TT-6194 Terminal Control Unit, TT-6006 Message Terminal), Furuno (FELCOM 18, FELCOM 19, IC-118, IC-119), JRC (JUE-95LT, JUE-87, NAF-253GM), Cobham (Sailor 6120, 6130), Samyung (SN-100).
