PRE OWNED SAMYUNG SI-70A SAMYUNG SI-70A MARINE AIS

PRODUCT DATA SHEET: SAMYUNG SI-70A CLASS-A AIS (USED/REFURBISHED)

PRODUCT OVERVIEW

The Samyung SI-70A is an IMO-compliant Class-A AIS system designed for commercial vessels, providing a high-resolution color display for superior situational awareness. It integrates a powerful transceiver and an intuitive user interface into a single, sleek unit. Known for its multi-GNSS support (GPS, GLONASS, Galileo, BeiDou), the SI-70A ensures stable and accurate positioning even in difficult maritime environments. As a used or refurbished unit, it is highly sought after for its modern features, including SD card software updates and extensive NMEA connectivity.

TECHNICAL SPECIFICATIONS

Model: Samyung SI-70A

Display: 7-inch Wide TFT Color LCD (800 x 480 pixels)

Output Power: 12.5 W / 1 W (Automatic or Manual)

Frequency Range: 156.025 MHz to 162.025 MHz

GNSS Receiver: 72-channel engine (GPS, GLONASS, BeiDou, Galileo, QZSS)

Interfaces: * 3x Sensor Input ports (IEC 61162-1/2)

1x Pilot/Aux/Long Range I/O port

2x RS-232 Outputs (for PC/External peripherals)

Storage: SD Card slot (Supports 1GB to 16GB for software updates)

Power Supply: 12 VDC to 24 VDC (Isolated, 11V–36V range)

Weight: Main Unit: 2.5 kg

KEY FEATURES & APPLICATIONS

High-Resolution Color Plotter: The 7-inch widescreen display offers a vivid "radar-style" view with color-coded AIS targets, allowing for much faster identification of dangerous vessels compared to monochrome screens.

Multi-GNSS Reception: By tracking multiple satellite constellations simultaneously, the SI-70A provides more reliable positioning and timing data, essential for busy shipping lanes.

User-Friendly Interface: Features a dedicated numeric keypad and one-touch function keys (F1–F4) for rapid access to menus, target lists, and message settings.

Internal Self-Diagnosis: An upgraded fault-diagnosis system continuously monitors internal PCB health and antenna status, alerting the crew immediately to any system failures.

Day/Night Display Modes: Optimized color palettes prevent eye strain during night watches while maintaining high visibility in direct sunlight.

Flexible Target Sorting: Navigators can sort the target ship list by MMSI, Distance, or Bearing (ascending/descending), or search directly by ship name.

Multilingual Menu: Supports English, Korean, Chinese, and Russian languages, making it a versatile choice for international crews.

TYPICAL CONDITION (USED/REFURBISHED)

Standard Components: Usually sold with the SI-70A Main Unit, GNSS-70 Antenna, and VHF Antenna. (Optional Terminal Box TB-70S may be included).

Technical Status: Refurbished units are typically tested for color LCD clarity (no dead pixels) and VHF transmit power consistency.

Retrofit Potential: Its wide voltage range (11-36V) makes it very easy to install on various vessel types without needing dedicated power converters.
