PRE OWNED SPERRY MARINE NAVI 5000 SPERRY MARINE NAVI 5000 MARINE AUTOPILOT

The Sperry Marine NAVIPILOT 5000 is an intelligent, self-tuning autopilot designed to provide the highest levels of steering accuracy and operational safety. Building on the success of previous models, the 5000 series features a modern, intuitive user interface with a large color display and touch-screen capabilities. Its advanced adaptive algorithms continuously monitor the vessel’s behavior, automatically adjusting rudder response to compensate for shifts in draft, speed, and sea state.

The system is fully integrated into the NAVINET 4000 steering control network, allowing for modular expansion and seamless communication with other Sperry Marine sensors. By minimizing unnecessary rudder movement, the NAVIPILOT 5000 helps vessel operators achieve maximum fuel efficiency and reduces the mechanical load on the steering gear, making it a sustainable choice for modern fleet management.

TECHNICAL SPECIFICATIONS

-- Model: NAVIPILOT 5000

-- Manufacturer: Sperry Marine (Northrop Grumman)

-- Control Unit: 5.7-inch High-Resolution Color TFT LCD

-- Supply Voltage: 24V DC (18V to 36V DC)

-- Power Consumption: 15 W

-- Interface: Ethernet / CAN bus (NAVINET 4000)

-- Heading Inputs: 2x NMEA 0183 (RS-422) / NMEA 2000 compatible

-- Steering Modes: AUTO, NAV (Track Control), Heading, Wind, Draft-Dependent Adaptive

-- Operating Temperature: -15C to +55C

-- Protection Class: IP56 (Front Face)

-- Mounting Type: Console / Flush Mount

-- Compliance: IMO A.342(X), MSC.64(67), ISO 11674, Wheelmark Certified

KEY FEATURES & APPLICATIONS

-- Advanced Self-Tuning: The pilot automatically identifies and remembers the vessel’s steering characteristics, ensuring optimal performance from the moment it is engaged.

-- Fuel-Saving Logic: Incorporates a "Fine" and "Coarse" steering mode that reduces rudder drag during long-haul transits, directly lowering fuel consumption.

-- Touch-Screen Interface: Provides a modern, user-friendly experience with clear graphical menus and real-time rudder angle plotting for enhanced situational awareness.

-- Track Control Category C: Enables high-precision path following when connected to a VisionMaster Net ECDIS, ideal for narrow channel navigation.

-- High-Speed Sensitivity: Optimized for High-Speed Craft (HSC), offering the rapid response times necessary to maintain safety at speeds exceeding 40 knots.

-- Redundant Networking: Built on a robust Ethernet backbone that ensures data integrity even in the event of a single network cable failure.

TYPICAL CONDITION (USED/REFURBISHED)

When we supply refurbished NAVIPILOT 5000 units from the Alang/Bhavnagar yards, we focus on the integrity of the color TFT display and touch-screen responsiveness. We verify that the internal CPU has the latest firmware updates and that the adaptive memory has been reset for a fresh vessel calibration. All communication ports (CAN bus and Ethernet) are bench-tested for signal stability, and the cooling fans in the processor unit are checked for silent, efficient operation.

COMPATIBLE BRAND MODELS:Sperry Marine NAVIPILOT 5000, Sperry Marine NAVIPILOT 4000, Sperry Marine VisionMaster Net, Sperry Marine NAVIGAT 200, Sperry Marine NAVIGAT 3000, Raytheon Anschütz NautoPilot 5000, Raytheon Anschütz NP5500, Furuno NAVpilot-711C, JRC JAP-701, Tokyo Keiki PR-9000, Yokogawa PT900.
