PRE OWNED YOUNG 86000 YOUNG 86000 ANEMOMETER

R.M. YOUNG 06206 MARINE WIND TRACKER

PRODUCT OVERVIEW

The R.M. Young 06206 Marine Wind Tracker is a high-performance bridge display designed specifically for the commercial maritime industry. It provides a clear, graphical representation of wind speed and direction, including maximum wind gust data.

Unlike standard industrial trackers, the 06206 is "Marine-Ready," featuring specialized firmware to calculate True Wind data when interfaced with a ship's GPS or Compass. It is the perfect companion for the 86000-series ultrasonic anemometers often found in Bhavnagar’s refurbished stocks.

TECHNICAL SPECIFICATIONS

Model: R.M. Young 06206 Marine Wind Tracker

Display: 360-degree LED circle (Direction) + Large Digital LED (Speed)

Input: NMEA 0183 ($--MWV, $--RMC, $--GLL, $--HDG)

Output: RS-485, RS-232, and 4-20mA Analog

Power Supply: 12-30 VDC, 4.5 Watts

Alarms: User-definable High-Wind Alarm (Visual and Audible)

Dimensions: 144mm x 144mm x 36mm (Standard DIN)

KEY FEATURES & APPLICATIONS

True Wind Calculation: Automatically computes True Wind Speed and Direction by integrating ship's heading and speed over ground (SOG).

Wind Gust Memory: Features a "Max" button that instantly recalls the highest wind speed recorded during a voyage.

Day/Night Dimming: Front-panel brightness control is optimized for bridge watchstanding, ensuring clear visibility without night-vision interference.

NMEA Interfacing: Directly compatible with Furuno, JRC, and Sperry bridge systems for data logging and VDR recording.

Rugged Enclosure: Designed for console mounting with a gasketed front for protection against salt-spray and humidity.

TYPICAL CONDITION (USED/REFURBISHED)

These units are highly sought after because they are almost indestructible. Refurbished units are tested for LED segment clarity and terminal block integrity. We ensure the internal battery/memory for settings is functional so that calibration data is not lost during power cycles.

COMPATIBLE BRAND MODELS:

R.M. Young (06201, 86000, 86106, 05103, 05106), Gill Instruments (WindSonic, WindObserver), Vaisala (WXT536), Furuno (FI-5001, RD-33, RD-50), B&G (WS310, WS700), JRC (NCM-879), DEIF (WSS, WSS-L, WSS-700), Sperry Marine (879.50), Walker (P1249, P247).
